Acrylic Waterproof Bopp Jumbo Roll Slitting Rewinding Machine
Acrylic Waterproof Large Transparent Bopp Tape Jumbo Roll Slitting Rewinding Machine
Acrylic Waterproof Large Transparent Bopp Tape Jumbo Roll Slitting Rewinding Machine for BOPP/OPP adhesive/Glass paper tape/cellophane paper with high speed.
1. Crowned stretch roll: adopt “pulling flat board” device to eliminate the corrugated phenomenon in the course of sending materials of adhesive tapes.
2. centralized panel for easy operation. Control operation speed by variable frequency and variable speed.
3. three-step length setting provides extremely smooth rewinding operations to give accurate rewinding length.
4. Automatic four-shaft exchange is adopted. Once rewinding operation is completed, the machine will automatically perform shaft changes.
5. Pneumatic braking is to control the unwind tension. The rewind tension is controlled by the clutch and independent slide setting for free adjustment of the tensile force.
3. Technical parameters Acrylic Waterproof Large Transparent Bopp Tape Jumbo Roll Slitting Rewinding Machine :
|
Model |
YU-210 |
|
Effective width |
1300 mm or 1600mm |
|
Max. unwind diameter |
800mm |
|
Min. slitting width |
12mm |
|
Max. rewind diameter(shaft1") exchange 4 shafts |
75mm |
|
Max. rewind diameter(shaft3") exchange 4 shafts |
200mm |
|
Max. rewind diameter(shaft3") exchange 2 shafts |
300mm |
|
Machine speed |
0-180m/min |
|
Slitting blade |
0.2×22×60mm |
|
Main power |
5.5KW |
Finish products
