Sublimation Transfer Paper Coating Macking Machine Equipment

Sublimation Transfer Paper Coating Machine

I. Main Application Sublimation Transfer Paper Coating Machine :

1.1 Used to produce sublimation heat transfer paper;

1.2 Suitable material:

1.2.1 Paper: 60-120g/m2;

1.2.2 Adhesive: Water base glue;

1.2.3 Solid content of adhesive:.

Technical parameters Sublimation Transfer Paper Coating Machine:

Basis weight of base paper: 60-120gsm

The moisture of the base paper: 4-7%

The machine deckle: 500-1800mm

The dynamic balance speed: 50-150m/min

The working speed: 150-250m/min

Coating system: comma blade coating and air knife coating

Unwinder & winder: auto splicing

Drying system: steam or gas burnning

Tension control: high precision DFE loadcell control

Electrical control system: Siemens PLC system

The steam pressure required: 0.8-1.0Mpa

Power supply: 3phase*380V/50Hz

Control voltage: 220V/50Hz & 24 VDC

Compressed air required: 0.6MPa, Dewatered with filtration treatment
