10S2P Custom Lithium Battery Packs
Super thin 10S2P li ion 5Ah 36v Custom Lithium Battery Packs electric skateboard
| Items | Specifications |
| Type | Lithium ion battery |
| Nominal voltage | 36V |
| Nominal Capacity | 5Ah |
| Dimension | Customized |
| Weight | Approx: 1kg |
| Max.charge current | 1.0C |
| Max.discharge current | 10A or according to customer requirement |
| Charge current |
Standard Charging: 0.5C Rapid charge: 1.0C |
| Standard Charging method |
CC-CV(constant voltage with limited current) |
| Charging time | 0.2C: 5-6 hours; 0.5C: 2-3 hours; Max 1C: 1-2 hours |
| Cycle life |
500-1000 times according to customer use method |
| Operating temperature |
Charging: 0 °C ~+45 °C Discharging: -20 °C ~+60 °C |
| Storage temperature |
-20°C~+60 °C |
| Standard Set | |
| Capacity: | 5Ah |
| Nominal Voltage: | 36V |
| Configguration | 10S2P |
| DIMENSION | customized |
| OEM/ODM | acceptable |
1. Don’t connect the positive terminal and the negative terminal of the battery directly.
2. Don’t expose the battery to high-temperature locations. Such as heating, sunny and near fire, etc.
3. Don’t place the battery in water, salt, acidic or alkalescent liquid and avoid being caught in rain.
4. Don’t disassemble the battery without technician’s guide.
5. Keep in shady, cool and dry condition if battery not work for a long time and charge the battery per 3 months.
6. Please use the exclusive charger to charge the battery.
1. Long life, large capacity and good shock resistance
2. Low self-discharge and good discharge performance at low temperature
3. Strong charging acceptance and quick-charging capability
4. Strong over-discharge resistance and charge retention
5. Maintenance-free and no acid or water for maintenance in usage
6. Excellent large current discharge performance, and have obvious advantages in startup and climbing
7. High temperature performance
8. Environmental friendly
9. Lighter weight smaller size
10. Most safe no explosion no fire
| Packaging | Normal OPP bag; PVC bag; Customized box |
| Carton Size | 60cm*40cm*35cm or customized,24 bags/ carton |
| Gross weight | 9.0 KGS |
| MOQ | 10pcs |
Q: How about the warranty of li ion batteries?
A: Warranty of li-ion battery could be as long as 1 year and LiFePO4 is 2 years.
Q: Payment terms?
A: we could receive the payment via PayPal or bank transfer or Western union etc.
Q: How long will be the delivery?
A: Usually, batteries in stock, delivery 3-5 days. Batteries without stock, delivery 10-12 days.
Q: Could you provide OEM service?
A: Yes, we could. we could also provide customized packaging if you need.
Q: MOQ?
A: No limit for standard models.
Q: How to contact with you?
A: You could send me a email at below email box. Or use below contact information:
