ASME/ANSI B16.11 Socket Pipe Fittings Elbow Forging And Socket Threaded Pipe Fittings

The socket elbow is mainly a high-pressure elbow pipe connection fitting that is formed from round steel or steel ingot die-forged blank, and then machined by a lathe. It is a kind of forged socket series pipe fittings.

Common standards for folding
Commonly used standards for socket elbows include GB/T14383-93, GB/T14383-2008, American Standard ASME B16.11, Petrochemical Standard SH3410, Ministry of Chemical Industry Standard HG/T21634, etc.

Folding specifications
According to the form, it is divided into 45° socket elbow and 90° socket elbow

According to common standards, the specifications of socket elbows are DN6, DN8, DN10, DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100. The commonly used order specification is DN15----DN50. If the specifications are beyond the scope, we can communicate with customers on the design and processing of drawings.
