Three Phase Automatic Voltage Regulator With Stepless And Breakerless Voltage Regulation
Price:
Negotiable
MOQ:
1UNIT
Delivery Time:
15
Brand:
ARK
Product Description
Three Phase Automatic Voltage Regulator With Stepless And Breakerless Voltage Regulation
Products Description
Product Paramenters
| Type | Series 220V | Series 380V |
| Norminal Voltage | AC220V (±20%) | AC380V (±20%) |
| Rated Frequency | 50Hz±5% | |
|
Compensating Current
|
30kVA |
30kVA, 45kVA, 60kVA, 80kVA, 100kVA, 120kVA, 250kVA, 500kVA |
| Network | L/N | 3P4W |
| Current Harmonic Distortion Rate | Increment ≤1% | |
| Voltage Harmonic Distortion Rate | Increment ≤1% | |
| Output Voltage | 220V±1% | |
| Voltage Regulating Way | Stepless, Breakerless | |
| Regulating Way | Separate phase regulation | |
| Power Factor | 0.5 lag to 0.7 lead | |
| Machine Efficiency | ≥95% | |
| SCR Bypass |
SCR Bypass Yes, with Relay |
|
| Display |
7-inch touch screen, providing parameter settings, power information display, fault records, historical curves, etc. |
|
| Protection Function |
Input overvoltage/undervoltage protection, output overvoltage/undervoltage protection, input overcurrent protection, transformer overtemperature protection, output overload protection, etc. |
|
| Communication Methods |
Four-channel RS485 communication interface (support GPRS/WIFI wireless communication), Ethernet, USB |
|
| Altitude without Derating | ＜2000m | |
| Temperature | -20℃ ~ 50℃ | |
| Humidity | ＜90% RH | |
| Pollution Level | Below level Ⅲ | |
| Noise | ≤65dB | |
| Inlet Way | Top entry | |
| Protection Grade | IP20 | |
