250V M12 4 Pin Waterproof Connector Plug Cable Straight Assembly PA GF
Price:
negotiable
MOQ:
10
Delivery Time:
7~14
Brand:
RIGOAL
Product Description
waterproof ip67 straight assembly 4pin sensor conector plug cable panel mounted pcb a d code female m12 4 pin connector
| General Infomation | |||
| Standard | IEC 61076-2-101 | Insulation Resistance | ≥100MΩ |
| Ambient Temperature | -25℃~+90℃ | Contact Resistance | ≤5mΩ |
| Connector Insert | Plastic(PA+GF) | Shielding | Unavailable |
| Connector Contacts | Plastic(PA+GF) | Seal/O-ring | Epoxy resin/FKM |
| Coupling Nut/Screw | Plastic(PA+GF) | Mating Endurance | >500 cycles |
| IP Rating | IP68/IP69K in locked condition | Certificate | UL/CE/ROHS/IP67/REACH/IP68 |
The M12 series features sensor and actuator connectors with locking thread for electronics automation, process control,
and commercial electronics.
We offer many different cable connectors, panel mount receptacles, field attachable/ installable connectors and various accessories.
Our connectors have industry standard A/B/C/D/S/T/X cording, for both screw locking and quick-locking styles.
