7.5KW Kraft Paper Slitting Machine
1100D Kraft Paper Slitting Machine With Friction Air Shaft
Product Description
High speed paper film plastic roll to roll slitting rewinding machine
The machine is suitable for sltting paper, film material from jumbol roll to small narrow rolls in high speed.
Main features
1)The machine adpot PLC,touch screen
2) Meter counting system
3) Unwind use auto loading system, shaftless loading( which can suitable for 3 inch and 6 inch core both)
4) Rewinding with auto unloading frame
5) Unwind side use web guide system
6) With 10 sets slitting knife
Main Technical Specification:
|
Max web width |
1100mm |
|
Max rewinding diameter |
550mm |
|
Max. unwinding diameter |
700mm |
|
Min slitting width |
30mm |
|
Power Supplier |
AC380V, 3 phase |
|
Cutting precision |
0.2mm |
|
Cutting speed |
10-300m/min |
|
Overall dimensions(L*W*H) |
2.0m*2.1m*1.35m |
|
Machine weight |
2100kg |
Material details:
| Slitting material | paper,foil, PVC, |
| cutting knife | razor knife,round knife as your request |
| Unwind put diameter | can make machine according to your material max.size |
| Rewind diameter | can customize |
