Pulp Rotary 30 Kw Semi Automatic Egg Tray Machine Air Drying
Reliable Supplier Pulp Used Tray Making Machine Big Egg Dish Machine
Description For Egg Dish Machine
Product Type: Automatic waste paper roller egg tray manufacturing machine
Processing Type: Pulp Molding Machine
Approval: CE
Warranty: 12 Monthes
Rotary: 2 /4 /8 /12 Faces
Forming Platen Size: 1600 x 400 mm / 1950 x 420 mm / 2350 x 420 mm
Capacity: 1500 – 20000 pcs/hr (30-egg tray)
Matches with 6-layer dryer, energy efficient and conserve energy
Large capacity fully automatic paper egg tray machine equipped with automatic hot pressing and intelligent conveying stacking technology.
Mainly applied for egg tray, egg carton, fruit tray, cup carrier, bottle tray etc.
Features for fully automatic small pulp drm egg tray machine
1. Raw material: all waste paper like old newspaper,magazines,books,A4 paper etc, and easy to get.
2. Automation: Fully-automatic control
3. Quality standard: CE
4. 100% environmentally production process.
5. Engineers available to service machinery overseas
Specification:
| Egg Tray Mold Quantity | 3pcs | |
| Raw material | Waste paper | |
| Egg tray Capacity(pcs/hour) | 1000 | |
| Net welght per plece (gram) | 70-75 | |
| waste paper consumption | 0.13ton / h | |
| water Consumption | 0.3ton / h | |
| Natural Gas Consumption of Dryer | 60cbmh | |
| Boiler model (natural gas fuel Kcal) | 600*103 | |
| Worker requirement | 4-6workers | |
| Power Requirement | Without dryer | 45Kw |
| with dryer | 65Kw | |
| Area of workshop | without dryer | More than 150 M |
| with dryer | More than 320 M dryer-18M |
|
| Container Requirement | Without dryer | 40f*1 |
| with dryer | 40ft3 | |
| Remarks: 1.The Capacity calculaled base on 30-packed egg tray(size 300x300mm. weight 70g~75g). 2.Workshop size is for reference only and could be adjusted according to actual size of client's plant. |
||
Semi Automatic Egg Tray Machine Process:
1. Pulping system
Pulper, 1.0M3,15kw;
vibration screen, 0.9M2,3kw;
mixer; pulp pump;water pump,control cabinet for pulping system,etc
2. Forming system
Consist of 1pc of forming platen and 1 pc of transfering platen.
Platen size: 1100x470mm,4sets of 30-cell egg tray molds can be mounted on forming platen.
Forming efficiency: 5-6cycles/min;
Equiped with vacuum auto draining system;auto cleaning system for the forming mold and auto control cabinet.
3. Drying system
Outline dimension: 20080x2650x3600mm;
Single layer conveying chain; heated by section;multi burners;
Six layers drying line, energy saving and saving place
The temperature of each section can be adjusted independently;burners with French or Italian brand;
The energy for option: LPG, GAS, diesel oil,Equiped with auto control cabinet.
Paper pulp molding molds
The molds are the spirit part of the paper pulp molding production line.
The forming molds is the molds which to transform the fiber pulp into the wet trays.
The forming molds are including forming and transferring 2 different type molds.
The materials for the forming molds are copper, aluminum, plastic and aluminum-plastic composite materials and so on.
Drying System
The drying system is the third section of the egg tray production line. Generally, the wet trays moisture content is 70%. So drying system is required for drying the wet trays.for this small capacity machine ,we suggest dry under sun or single layer metallic dryer.
After Sale
1.One Year Guarantee for Whole Machine
2.24 Hours Technical Support by Email
3.Calling or Door-to-Door Service
4.Use Friendly English Software,User Manual and Detailed Video
Our Company
Hebei wongs machinery equipment co.,ltd is the first manufacturer to develop egg tray machines in Shijiazhuang Area. With more than 30 years experience, we have a strong scientific research in improving the Production Process, Product Structure and performance. Now our technical team can make multifunction, high efficiency, energy saving egg tray machines.
There are various types and output of egg tray making machines can be supplied by our company ,such as 1000pcs per hour, 2500pcs, 3000pcs per hour, 3500pcs, 4000pcs per hour, 5000pcs/hr,6000pcs/hr,7000pcs/hr,and so on .You only can tell me what capacity machine do you want,our professional engineer will design the most suitable machine for you!
