Waste Paper Recycle Plc Egg Tray Making Machine Middle Capacity
Waste Paper Recycle Making Machine For Egg Tray Middle Capacity
Machine Introduction:
Machine for make paper egg tray,egg tray making machine,egg tray machine,paper tray machine.pulp moulding machine
The quality of our egg tray making machines is superior to that of other suppliers,and our prices are lower than theirs.
Egg tray forming machine is a kind of machine which absorbs paper pulp-the raw material, on the surface of mould by vacuum to get various shape and ratio of wet and dry by regulating time. After such working procedure as transferring moulds, releasing moulds to complete paper tray production. Our forming machines adopt advanced PLC programmable controller; selecting of high quality electronic devices and pneumatic components; using stainless steel pulp barrels with high performance and long service life.
Specification:
|
Tech Date |
|
| Production name | Egg Tray Machine |
| Model | 4 side |
| Capacity | 3000pcs/h |
| No. of Molds | 4 plate + 1 plate |
| Labor needed | 5-6 |
| Template Size | 1490mm*470mm |
| Dimension |
3200*2000*2300mm |
| Voltage | 380V,voltage can be customized |
| Power | 80kw |
| Rotary speed | 19 times per minute |
| Drying method | Brick dryer and metal dryer |
Advantages:
Our paper egg tray molding equipment have semi-automatic, full-automatic,Excellent automatic integral device etc with different specification different level.Forming Machine include: Rotary type, flip type,
Reciprocating type and Rolled type. Drying System:Energy. coal/ dry wood/ LPG/GAS/Diesel oil, it may be drying naturally in less rain area. Packing System: We have shaping machine with pneumatic or hydraulic transmission system, we will give you best design according to our requirement.
Equipments List
Drying system
(1) Natural drying method: The product is dried directly by weather and natural wind.
(2) Traditional drying: brick tunnel kiln, the heat source can be natural gas, diesel, coal, dry wood, liquefied petroleum gas and other heat sources.
(3) New-type multi-layer drying line: The 6-layer metal drying line can save more than 30% energy than transmission drying. The main heat source is natural gas, diesel, liquefied petroleum gas, methanol and other clean energy sources.
Finished Photos for show
FAQ
R:What kinds of the egg tray machines you product?
A:We don't just product egg tray making machine/egg box machine/egg dish machine/egg plate machine .we can also product the fruit tray molds,seeding tray molds .we can offer drying equipment.
R:What is your the Minimum and capacity maximum egg tray machine.
A:1000 pieces is the minimum and the 6000-9000 is the maximum,they are in the factory .if you want other minimum or minimum,click here contact us .
R:Are you a factory?
A:Yes,we have our own factory,you can tell us your requirement,we can product them!
R:How the time the Warranty?
A:1 year,the machine have any product ,you can contact us after service ,the factory can offer the parts for free.
R:I don't know how to install the machine?
A:Don't worry,we have professional personal help your install the machine in your country!
