Pulp Plastic Molding Paper Egg Tray Machine Metallic Dryer System
Paper Egg Tray Making Product Machine To Make Egg Trays Pulp Molding Machine
Paper egg tray Machine Introduction:
Up to now we have various kinds capacity to the machine:800pcs/h,1500pcs/h,2000pcs/h,2500pcs/h,3000pcs/h,4000pcs/h,6000pcs/h and we still have two different kinds of dryer system compraised:the metallic dryer system and the brick kiln dryer system .Three systems are included:the pulping system,the forming system and the dryer system.
Raw material:
The raw materials are mainly from various pulp boards such as reed pulp, straw pulp, slurry, bamboo pulp and wood pulp, and waste paperboard, waste paper box paper, waste white paper, paper mill tail pulp waste, etc. Waste paper, widely sourced and easy to collect.
Process for egg tray machine:
1. Pulp molding system: Hydraulic pulper, High-frequency vibration sieve frame, Pulp pump, Strengthening of self-priming pump, Agitator, Control cabinet of pulping system
2. Forming system: Rotary forming machine, Molds, Vacuum pump, Screw Air Compressor, Vacuum buffer tank, Air compressor storage tank, White Water pump, High-pressure water pump, Refiner machine, Power cabinet of forming system
3. Drying system: Conveyor, Blower, Induced fan, Burner, Bellows, etc
4. Packing system: Packing machine
Paper Egg Tray Mchine Specification:
| Model | 1-3 Egg Tray Production Line |
| Drying Method | Natural In Sun |
| Output per hour | 1000 pieces |
| Mold Quantity | 3 units forming molds and 3 units transfer molds |
| Total Power | 30KW |
| Workers | 3-4 workers |
| waste paper consumption | 85kg/hr |
| Water Consumption | 200kg/hr |
| Workshop area | More than 60m² |
Advantage
1.High production
2.Easy to install and operate
3.Rugged construction
4.Heat resistance
5.Competitive price
6.Green:No waste paper emission
7.Stable final product quality(Good&strong look, same weight and size)
8.Space saving & low investment
9.Best pre-sale, in-sale and after-sale service.
Drying system
Drying method: single layer metal dryer
Our Sales Service
1.We will give more details for your concern problem through email, whatsapp and phone the first time we have received your inquiry.
2.We will arrange engineers to help you install machine. And our engineer will train your workers.
3.If you meet any problems during operating, you can contact us to help you to solve.
Our certificate
FAQ
Q: What's the guarantee for the egg tray machine and equipment?
A: Usually the forming machine guarantee is one year, and motors guarantee is half of an year.
Q:How to choose a suitable egg tray making machine and production lines?
A:Just need tell us your requirement.We will make a good production plan according to your requirements.
Q:Do you provide sample service?
A:We can send you paper samples, which is produced by our machine.
You also can send us the paper sample that you want to produce by DHL, etc.We will design according to your paper samples.
Q:What is the raw material of egg tray making machine?
A:Waste paper,Cardboard,Magazine,Newspaper,ect
Q:Can you offer technician aboard for training workers?
A:Yes, we have team for installation guidance aboard, technicians will be sent for installation guidance and training workers .
Q:Where is your company located?
A: it is located in Shijiazhuang city,Hebei province, China.
Our Company
Hebei Wongs Machinery Equipment Co., Ltd is a large enterprise which specialized in producing of various kinds of paper pulp molding products and equipments ,We can product all kinds of paper pulp molding products ,such as egg tray ,egg box ,bottle tray ,paper shoes stretcher ,cans and milk box .Our equipments have already been exported to more than 30 countries,Algeria,Russia,Egype,Ukraine,Australia,Argentina,Brazil,Saudi Arabia,Libya,Syria.Our paper egg tray molding equipment have semi-automatic ,full -automatic,Excellent automatic integral device etc,with different specification different level.Forming Machine include :Rotary type,flip type ,Reciprocating type and Rolled,Drying System:Energy:coal/dry wool/LPG/GAS/Diesel oil,it may be drying naturally in less rain area.Packing System :We have shipping machine withe pneumatic or hydraulic transmission system,we will give you best design according to our requirement.
