16bit Outdoor LED Display Module / P6.67 Full Color LED Module 100000H
Outdoor led display module P6.67 full color led billboard sign panel module
Function and Technology Character Introduction:
1, Bright colors, high brightness, high-quality tubes, stable quality, high brightness, good color consistency, and long service life
2, The color uniformity of the display screen is super high, and the screen picture is more delicate.
3, The module can support the maintenance and installation before magnetic suction, the maintenance before the simple iron cabinet, and the maintenance before the die-cast aluminum cabinet. The installation method is selected according to the on-site construction environment, and the disassembly is simple and quick.
4, Strong protective performance, with moisture-proof, dust-proof, anti-collision, anti-oil stain, anti-oxidation, anti-static properties, and has the characteristics of abrasion resistance and easy cleaning.
Products Applications:
Widely used in churches, control command centers, video surveillance centers, high-definition information release, conference display systems and other commercial venues
SPECIFICATIONS Parameters:
| Pixel pitch (mm) | P6.67 |
| Module size(mm) | 320X160mm |
| Pixel density (point /㎡) | 22500 |
| Module resolution (WxH) | 48X24 |
| Pixel structure | SMD3535 |
| scanning method | 1/6 |
| Refresh rate (Hz) | ≥3840Hz |
| White balance brightness (nits) | ≥5500 |
| Color temperature (K) | 1500-12000Adjustable |
| Gray scale | 16bit |
| Frame change frequency | 60-120Hz |
| Viewing angle (horizontal/vertical°) | 160/160 |
| Protection level (front/back) | IP65/IP54 |
| Power consumption (peak/average W/㎡) | 850/300 |
weiye color series led strip display screen advantage:
1, Use outdoor dedicated independent waterproof module, no need to worry about water vapor erosion module, unique mask design, dustproof, waterproof and corrosion-proof, protection level reaches IP65
2, The circuit board adopts wave soldering process and has a green oil oxygen barrier to prevent moisture and oxidation of the circuit and increase the service life.
3, It has strong protective performance, waterproof, moisture-proof, dust-proof, anti-collision, anti-oil stain, anti-oxidation, anti-static properties, and has the characteristics of abrasion resistance and easy cleaning.
4,The weight is easy to install and disassemble, the LED is driven by a constant current method, the light is uniform, and the power consumption is low. Each pixel is composed of 1R1G1B.
5. High-brush chip, refreshing up to 3840Hz, constant output current, high-refresh effect and no flicker when taking pictures, ensuring high-definition and delicate display pictures
