800NITS Patch Full Color LED Displays Panel P3 Indoor LED Module 100000H
High-brightness P3 patch high-definition full-color indoor LED display panel module
Function and Technology Character Introduction:
1, The front of the module is filled with glue to prevent the front lamp tube from getting wet. The back of the PCB is coated with tri-proof paint to prevent moisture and dust.
2, The viewing angle is wide, the contrast is high, the visualization angle is up to 160°, the up and down, left and right viewing is barrier-free and non-reflective, the mask ink color consistency is good, and the contrast is high.
3, Stable refresh performance, dual support for computer and mobile phone control, stable performance, no flicker, good display effect, high brightness and bright colors, attracting attention.
4, Strong protective performance, with moisture-proof, dust-proof, anti-collision, anti-oil stain, anti-oxidation, anti-static properties, and has the characteristics of abrasion resistance and easy cleaning.
Products Applications:
Widely used in churches, control command centers, video surveillance centers, high-definition information release, conference display systems and other commercial venues
SPECIFICATIONS Parameters:
| Pixel pitch (mm) | P3 |
| Module size(mm) | 192X192mm |
| Pixel density (point /㎡) | 111111 |
| Module resolution (WxH) | 64X64 |
| Pixel structure | SMD2020 |
| scanning method | 1/32 |
| Refresh rate (Hz) | ≥3840Hz |
| White balance brightness (nits) | ≥800 |
| Color temperature (K) | 1500-12000Adjustable |
| Gray scale | 16bit |
| Frame change frequency | 60-120Hz |
| Viewing angle (horizontal/vertical°) | 160/160 |
| Protection level (front/back) | IP31/IP45 |
| Power consumption (peak/average W/㎡) | 850/300 |
weiye color series led strip display screen advantage:
1, High-quality bottom shell kits and masks, using anti-deformation module bottom shell kits, high hardness and strength, to ensure that the screen body is flat and not deformed
2,Super anti-aging, after high temperature 60 degrees, low temperature minus 20 degrees white balance aging test, it still works normally.
3, The weight is easy to install and disassemble, the LED is driven by a constant current method, the light is uniform, and the power consumption is low. Each pixel is composed of 1R1G1B.
4, The module high-performance plastic fiber kit can effectively block moisture, dust and other substances from entering the inside of the LED display.
5. High-brush chip, refreshing up to 3840Hz, constant output current, high-refresh effect and no flicker when taking pictures, ensuring high-definition and delicate display pictures
