Buried Plastic HDPE Water Supply Pipe 4 Inch 90mm DN1600mm

Price Negotiable
Price: 0.5$/m(1~10m);0.43$/m(>1000m)
MOQ: 10 Meter/Meters
Delivery Time: Negotiable
Brand: HAIYANG
Product Description

High Quality Buried Plastic Pipe 4 Inch 90mm HDPE Water Supply Pipe

----------------------------------------



Basic Info.



HDPE drainage pipes are based on high-density polyethylene resin and are collectively referred to as thermoplastic round pipes without internal pressure, which are made by extrusion molding process. HDPE drainage pipe is a replacement product of traditional steel pipes and PVC drainage pipes.



Size   PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
    SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900   81.8 66.2 53.3 42.9 34.4
40 1000   90.2 72.5 59.3 47.7 38.2
48 1200     88.2 67.9 57.2 45.9
55 1400     102.9 82.4 66.7 53.5
60 1500     110.2 88.2 71.4 57.6
65 1600     117.6 94.1 76.2 61.2





Advantage



1. Has good weather resistance (including UV resistance) and long-term thermal stability;
2. Corrosion resistance, no need for anti-corrosion treatment, long service life;
3. The inner wall is smooth, the water flow resistance is small, the flow capacity is large, and the construction cost is saved;
4. Good wear resistance and wear resistance;
5. It has good low temperature impact resistance and can be safely affected in the temperature range of -20~40℃;



Details










Application



1. Vertical and horizontal drainage and permeation of expressways;
2. Vertical and horizontal drainage on the back of various retaining walls and side ditches of expressways;
3. Drainage of tunnels and underpasses;
4. Water supply and drainage for municipal engineering, water purification plants, sewage plants, garbage dumps, etc.;
5. Drainage of rest green areas such as golf courses, sports fields, parks, etc.;
6. Soil and water conservation of slope development in hillside land;
7. Underground drainage of the site preparation project;



Certificate
