Customized Electronic Thermometer PCB Circuit Board Prototype And Mass Production
Customized electronic thermometer pcb circuit board prototype and mass production
Shenzhen Senyan Circuit Co.,Ltd. is a professional PCB manufacturer specializing in single layer, double layer and multilayer pcb manufacturing, provides one-stop service from PCB manufacturing , components purchasing, PCB assembly to complete products building.
PCB Production Capability
•Material: FR-4,CEM-3,CEM-1,Aluminum,Polyimide fpc, HDI, Halogen-free , Ceramic boards
•Layer Counts: 1-12 LAYERS
•Board Thickness: 0.4mm—3.5mm
•Minimum Line & Space: 0.10mm
•Copper Thickness: 0.5-5OZ
•Min Drilling Hole(Finished): 0.2mm
•Hole Tolerance: PTH ±0.075mm NPTH ±0.05mm
•Solder Mask color: Green, black, red, white. Mini
. Solder Mask Clearance:0.05mm
•Silkscreen color: Green, white, red, yellow, black.
•Maximum Board Size: 580x1100mm
•Surface Finishing: HASL / HASL lead free, Immersion Silver/Gold/Tin, OSP, Gold plating
•Certificate: UL, ISO 9001, ISO 14001
•Special Requirements: Buried and blind vias + controlled impedance +BGA
•Profiling: Punching, Routing, V-CUT, Beveling
|
PCB Lead Time
|
||
|
Layer
|
Quick Turn/ Usual Time
|
Mass Production
|
|
2L
|
24hours /4 days
|
8-10 days
|
|
4L
|
48hours /5 days
|
10-12 days
|
|
6L
|
72hours /6 days
|
12-14 days
|
|
8L
|
72hours /7 days
|
16-18 days
|
|
10L
|
96hours /8 days
|
18-20 days
|
|
≥12L
|
96hours /10 days
|
18-20 days
|
Q1. What is needed for PCB and PCBA quotation?
PCB: Quantity, Gerber file and technic requirements ( material, surface finish treatment, copper thickness, borad thickness..)
PCBA: PCB information, Bom list. ( Testing documents...)
Q2. What file formats do you accept for PCB&PCBA production?
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BoM: Excel ( PDF, Word, TXT)
Q3. Are my files safe?
Your files ase held in complete safety and security. We protect the intellectual property for our customers in the whole process. All documents from customers are never shared with any third parties.
Q4. MOQ?
There is no MOQ in POE. We are able to handle Small as well as large volume production with flexibility.
Q5. Shipping cost?
The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost
