Chinese Factory Price Finely Processed Corrosion Resistant Wall Mounting Pipe FRP Flange

Description:

FRP Fitting,a wide range of fittings as elbows, reducers, tees, caps, flanges etc. is available.
Fittings are manufactured by the hand lay-up, contact molding and spray-up process. In hand lay-up and contact molding processes veil and alternate layers of mat and woven roving saturated with resin are applied on the mold. In spray-up process continuous strand roving is fed through a chopper gun, combined with catalyzed resin, and sprayed onto the mould surface.

Characteristics:

1. High anti-corrosion capability, long designed service time of 20 years;
2. Good hydraulic property, smooth inner surface with absolute roughness of 0.01mm, which is far less than that of carbon steel pipe or cast iron pipe;
3. Lightweight and facility to install and transport;
4. High specific intensity and reliable mechanical performance;
5. Low thermo-conductivity and small thermo-stress, which are allowed to be used in various conditions: exposed buried or suspended, in ocean or in deserts, freezing or humid;
6. Less joints and rapid assembly design: According to concrete engineering conditions, there are a several
ways of connection designed for clients to choose, which include Adhesive-bonded Plug Joint, Adhesive-
bonded End-to-end Joint, Flange Joint, Plug Joint with O-ring Gasket(with key-lock) and Thread Joint etc.
7. Good electrical insulation
8. Not rust, rot or corrode, not permeate, and without consequent pollution;
9. Anti-furring and vermiculate resistance;
10. Flexible design: the pipe can be designed on the shape and function according to its conditions of usage.
