High Pressure Screw Air Compressor 22kw 30hp Screw Compressor For Laser Cutting Machine
The Air Compressor for Fiber Laser Cutting Machine
Integrated compressed air system includes screw compressor, refrigerated air dryer, tank specialized for fiber laser cutting machine.
Product features
More Convenient
Integration of air compressor, air tank, and air dryer. It avoids the trouble of customers purchasing additional pipes and fittings. Use directly after installation, saving space.
More Reliable
Modular design, durable components, low noise and vibration, and easy maintenance.
Energy Efficiency
Using permanent magnet variable speed motor, specialized for laser cutting machine, reducing pressure leakage and more energy-saving.
Pure Compressed Air
High efficiency refrigerated dryer, multi-stage precision filter, oil content of gas is lower than 0.001 PPM, ensuring the purity of compressed air.
air delivery :2.41m³/min
Air tank:500L
Filter fineness,use four stage filters,particle content≤0.01μm oil content≤0.003PPM
Equipment configuration:screw air compressor, air tank ,air dryer,four stage filters,auto drain valve,inverter
Air dryer:16bar/3.6m³/2-10℃
Filter:16bar/3.5m³/4 pcs
| Model | Air Delivery (m3/min) | Rated exhaust pressure (Mpa) | Power (kW) | Noise (Db) | Outlet diameter (In) |
Dimension (mm) |
Weight (Kg) | Exhaust pressure dew point (ºC) |
Exhaust dust content (μm) |
Exhaust oil content (ppm) | Gas storage tank capacity (L) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DBZY-10A | 0.55 | 1.58 | 7.5 | 65 | G3/4 | 1418*700*1500 | 395 | 2~10 | 0.01 | 0.001 | 260 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DBZY-15A | 1.05 | 1.58 | 11 | 65 | G3/4 | 1882*790*1731 | 560 | 2~10 | 0.01 | 0.001 | 500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DBZY-20A | 1.51 | 1.58 | 15 | 65 | G3/4 | 1882*790*1731 | 572 | 2~10 | 0.01 | 0.001 | 500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DMZY-15A | 1.05 | 1.58 | 11 | 65 | G3/4 | 1882*790*1731 | 560 | 2~10 | 0.01 | 0.001 | 500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DMZY-20A | 1.52 | 1.58 | 15 | 65 | G3/4 | 1882*790*1731 | 572 | 2~10 | 0.01 | 0.001 | 500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DMZY-30A | 2.41 | 1.58 | 22 | 68 | G3/4 | 1882*1081*1801 | 630 | 2~10 | 0.01 | 0.001 | 500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DCZY-30A | 2.21 | 1.58 | 22 | 68 | G3/4 | 1882*1081*1801 | 630 | 2~10 | 0.01 | 0.001 | 500 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| CPBZY 15 | 1.16 | 1.58 | 15 | 68 | G3/4 | 1900*700*1650 | 560 | 2~10 | 0.01 | 0.001 | 350 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| CPMZY 15 | 1.16 | 1.58 | 20 | 68 | G3/4 | 1900*700*1650 | 560 | 2~10 | 0.01 | 0.001 | 350 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
DEHAHA COMPRESSOR JIANGSU CO.,LTD.with 26 years old history,we are specialized in Rotary Screw Air Compressor.Germany Standard and 13 years exporting experience help us won more than 30 loyal foreign agents.We warmly welcome your small trial order for quality or market test.
2.Are you a manufacturer or trading company?
We are professional manufacturer with big modern factory in Qidong,China,with professional design team.Both OEM & ODM service can be accepted.
3.Where is your factory located? How can I visit there?
Our factory is located in Qidong City, Jiangsu Province, China. We can pick up you from Shanghai, it's about 1 hour from Shanghai Pudong Airport to our factory. Warmly welcome to visit us!
4.What's your delivery time?
380V 50HZ we can delivery the goods within 14 days. Other electricity or other color we will delivery within 22 days,if urgently order, pls contact our sales in advance.
5.How long is your air compressor warranty?
One year for the whole machine and two years for screw air end, except consumable spare parts and we can provide some spare parts of the machines
6.How does your factory do regarding quality control?
Quality is everything. we always attach great importance to quality controlling from the very beginning to the very end. Our
factory has gained ISO9001:2015 authentication and CE certificate.
7.How long could your air compressor be used?
Generally, more than 10 years.
8. What's payment term?
T/T,L/C,D/P,Western Union,Paypal,Credit Card,and etc.Also we could accept USD, RMB, Euro and other currency.
9.How about your after-sales service?
(1) Provide customers with installation and commissioning online instructions.
(2) Well-trained engineers available to overseas service.
(3) Worldwide agents and after service available.
