Efficient High Speed V Grooving Machine V Groover Machine For Shower Room Frame
Price:
Negotiate
MOQ:
1 set
Delivery Time:
10-30days
Brand:
JM
Product Description
Efficient V Groove Cutter Machine for Shower Room frams
One-time forming of workpiece
The workpiece no longer needs to be shifted manually, which greatly improves the dimensional accuracy, saves labor costs, saves time costs and improves production efficiency.
Safeguarding against trouble
Whether the production equipment always has high utilization rate and brings good economic benefits determines the competitiveness of an enterprise. Therefore, we always accompany you with our rich experience and technical strength to provide global service. When the equipment goes out of the factory, I will prepare the service item introduction for you, so that you can know the relevant information about the equipment maintenance in time, and be fully prepared to avoid and control the subsequent expenditure.
Automatic Cycle Programming
The system can automatically cycle the workpiece according to the amount of cycle input without input one by one, which greatly reduces programming time and improves productivity.
| No. | Name | Parameter | Unit | |
| 1 | Max. Width of metal sheet | 1250 | mm | |
| 2 | Max. Length of metal sheet | 4000 | mm | |
| 3 | Max. thickness(Stainless steel) | 5 | mm | |
| 4 | Min. Thickness of metal sheet | 0.4 | mm | |
| 5 | Min.distance of the V from edge | 8 | mm | |
| 6 | Max. cutting speed of X axis | 120 | m/min | |
| 7 | Max .return speed of the X axis | 120 | m/min | |
| 8 | Max.distance of Y axis | 1250 | mm | |
| 9 | Resolution in Y1 axis | 0.001 | mm | |
| 10 | Repeated positioning accuracy | ±0.01 | mm | |
| 11 | Resolution in z axis | 0.001 | mm | |
| 12 | Repeated positioning accuracy | ±0.01 | mm | |
| 13 | Motor power | X axis | 5.5 | kW |
| Y1.Y2.Z axis | 1.0 | |||
| 14 | Overall dimension | Length | 5900 | mm |
| Width | 2000 | |||
| Height | 1550 | |||
