Welljets J4200 High Speed Industrial Thermal Inkjet Batch Coding TIJ Printer

Speed can up to 200 meters per min.

TIJ printer is printer based on thermal inkjet technology when the ink is pushing out of nozzles by activating heat. In the coding and marking industry, this type of technology is becoming increasingly popular due to its simplicity and maintenance-free nature. The system is modular and includes a controller, print driver, cables as well as a print cartridge with a print head inside. When you replace a cartridge, you replace the print engine as well.

Compact thermal inkjet printer range designed to print onto porous and non-porous surfaces with an overall print height up to 12.7mm. The ink type and colour can be changed in seconds simply by swapping the ink cartridge. The entire ink system is replaced each time the cartridge is replaced making the TJX completely maintenance-free.

Text from 1 to 12.7mm high in any font, detailed graphics, barcodes and 2D codes can be printed at up to 600 x 900dpi resolution using water-based or solvent-based inks. Variable data including date, time, offset date and sequential numbers can be automatically printed. The compact printhead can print forwards onto the side of products, down onto the top of products or forwards onto vertically moving webs such as on a vertical form fill seal (VFFS) machine.

The shaft encoder option allows Welljets J4200 printers to be used on variable speed, stop-start and continuous production lines with the encoder ensuring the print speed is matched to the product speed.

Overcoming Challenges of Legacy Printers

As technology continues to advance, printing or marking your products and packages can pose challenges and limitations for both legacy and even new systems. Continuous Inkjet (CIJ) and thermal transfer printing (TTO), in particular, have inherent limitations due to age, brand, ink, and configuration. CIJ printers may experience problems with ink smudging, substrate compatibility, frequent maintenance and printhead cleaning, and inconsistent print quality. Meanwhile, thermal transfer systems may struggle with ribbon cost, limited print durability, slow printing speeds, and frequent maintenance.

Industrial TIJ Systems You Can Count On

Fortunately, the L-Series overcomes these challenges. With our industrial printers, you can achieve consistent, high-quality prints without the headaches associated with other printing technologies. TIJ printing offers faster ink changeovers, a much lower maintenance burden, faster installation, easier operation, greater system flexibility, and extremely reliable marking and coding in contrast with CIJ and thermal transfer printing systems.

High-speed and quality.

Unmatched print speed with 600 dpi resolution delivers crisp, precise marks at the speed of your production line; and our superior in-house ink engineering ensures unparalleled performance on your substrates.
