20L Bead Grinder Horizontal Bead Mill Sand Mill In Paint Industry
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
20L Grinding Chamber Volume Horizontal Bead Mill for Milling Cutter in Paint Industry
Product Description:
DEGOLD bead mills and sand mills are suitable for continuous wet grinding of solids in liquid materials to reduce particle size.
Principle of Operation: The rotary grinding shaft drives all grinding mediums inside the grinding chamber. The grinding mediums passes the powers to the materials to reduce the particle size. Gap separator inside the horizontal bead mills separates the products and the grinding mediums. They are suitable for different viscosities formulations.
Different materials inside the horizontal bead mills can be choosen, such as SS304, hard alloy, mold steel, polyurethane, tungsten carbide, ceramic etc.
Application:
Technical Data
ZM Series:
| ZM0.3 | ZM1.4 | ZM5 | ZM15 | ZM20 | ZM30 | ZM50 | ||
| Effective grinding chamber volume (L) | 0.3 | 1.4 | 5 | 15 | 20 | 30 | 50 | |
| Main motor power (kW) | 0.75 | 2.2 | 7.5 | 15 | 18.5 | 22 | 30 | |
| Grinding shaft rotary speed (r/min) | 0~1500 | 0~2800 | 1650 | 1200 | 1200 | 1120 | 900 | |
| Adjustable range of materials flow (L/min) | 0~1 | 0~2 | 0~2 | 0~10 | 0~10 | 0~60 | ||
| Max. cooling water consumption (t/h) | 0.5 | 1 | 1 | 2 | 2 | 2.5 | ||
| Estimated productivity (kg/h) | 2~20 | 12~120 | 30~300 | 40~400 | 50~600 | 100~1000 | ||
| Dimension (mm) | L | 640 | 650 | 1250 | 1560 | 1600 | 1860 | 2100 |
| W | 410 | 570 | 900 | 1050 | 1050 | 1100 | 1150 | |
| H | 485 | 885 | 1250 | 1550 | 1550 | 1550 | 1650 | |
| Net weight (kg) | 50 | 500 | 700 | 800 | 980 | 1100 | 1300 | |
| Note: Technical data are different if there are some customized constructions. | ||||||||
ZM-X Series:
Model |
ZM5-X |
ZM15-X | ZM20-X | ZM30-X | ZM50-X | ZM100-X | ZM200-X | |
Effective grinding chamber volume (L) |
5 |
15 | 20 | 30 | 50 | 100 | 200 | |
| Main motor power (kW) | 11 | 18.5 | 22 | 30 | 37/45 | 45/55 | 55/75 | |
| Grinding shaft rotary speed (r/min) | 1650 | 1200 | 1200 | 1120 | 900 | 700 | 550 | |
| Adjustable range of materials flow (L/min) | 0~2 | 0~2 | 0~10 | 0~10 | 0~60 | 0~60 | 0~150 | |
| Max. cooling water consumption (t/h) | 1 | 1 | 2 | 2 | 2.5 | 2.5 | 3~4 | |
| Estimated productivity (kg/h) | 15~150 | 40~400 | 50~500 | 60~800 | 150~1500 | 150~1500 | 200~2000 | |
| Dimension (mm) |
Length | 1250 | 1560 | 1670 | 1760 | 1970 | 2175 | 2150 |
| Width | 900 | 1050 | 1050 | 1050 | 1150 | 1200 | 1200 | |
| Height | 1250 | 1550 | 1565 | 1585 | 1650 | 1880 | 2150 | |
| Net weight (kg) | 700 | 800 | 1000 | 1150 | 1350 | 2000 | 2500 | |
| Note: Technical data are different if there are some customized constructions. | ||||||||
Production Line
Our Services:
We can send out one or two technicians to buyer's location for providing installation and training service.
Packaging & Shipping:
Fumigation wooden box. The grinding medium usually be packed with the bead mill together.
