SR-SL-C08 M8 Proximity Sensor Approach Inductive Proximity Switch SR-SL-C08

Price Negotiable

Price: Large quantity price negotiable

MOQ: one

Delivery Time: 1-2 work days

Brand: SUPERISYS

Product Description

SR-SL-C08,Dc Inductive Approach Light,

Product characteristics

Operating voltage: 10-30VDC

Output function: NPN/PNP, NO/NC Optional

With polarity, overload, short circuit protection

Protection level: IP67

Direct outlet type, connector type

Operating temperature -25°C-+70%C

The use of optimized traditional technology and advanced packaging technology to ensure long-term stability in harsh environments

model	SR-SL-CR08	SR-SL-C08		SR-SL-C08--P3*		SR-SL2-C08		SR-SL2-C08--P3*
external diameter	M8	M8		M8		M8		M8
● flush ○unshielded	●	●	○	●	○	●	○	●	○
Sensing distance sn: mm	1.5mm	1.5mm	2mm	1.5mm	2mm	2mm	4mm	2mm	4mm
canning material	Stainless steel or nickel-plated copper	Stainless steel or nickel-plated copper		stainless steel		Stainless steel or nickel-plated copper		stainless steel
●tape light ○No indicator light	●	●		●		●		●












technical specification
working voltage	10-30VDC	10-30VDC/5-36VDC/10-55VDC/10-60VDC				10-30VDC
Allowable ripple voltage	＜10%
no-load current	＜10mA
Maximum load current	200mA
leak current	＜0.01mA
pressure drop	＜1.5V

switching frequency	2KHz					2KHz	1KHz	2KHz	1KHz
response time	0.1ms/0.1ms					0.1ms/0.1ms	0.2ms/0.2ms	0.1ms/0.1ms	0.2ms/0.2ms
Switching hysteresis	＜15%(Sr)
repeatability	＜1.0%(Sr)
level of protection	IP67
operating temperature	-25℃~+70℃
temperature drift	＜10%(Sr)
short-circuit protection	YES
overcurrent	220mA
Inductive surface material	POM


Size drawing (unit: mm)







Cable 2m	2.8φ3x0.15	2.8φ3x0.15或2.8φ4x0.15				2.8φ3x0.15或2.8φ4x0.15
Weight (approximate)	35g	40g		15g		40g		15g
