Intelligent Control and Precise Regulation of High-Temperature Heat Pumps

Price Negotiable
Price: negotiate a price
MOQ: 3 Unit
Delivery Time: Specific to the order based on regular products 5 to 7 days. Custom made for 30 days
Brand: Meidibao
Product Description

Meidibao Heat Pump Air Source Heat Pump Unit of Copeland Scroll Compressor R410A Heat Pump Air to Water



The Meidibao Air Source Heat Pump is an energy-efficient and high-performance solution for residential and commercial heating and hot water applications. Equipped with a Copeland Scroll Compressor and using R410A refrigerant, this unit ensures optimal energy efficiency, reliability, and eco-friendliness.

Key Features

Equipped with an intelligent control system, it can automatically adjust the operating parameters according to the ambient temperature and load, precisely control the temperature and humidity, and achieve unattended operation. Through remote monitoring, management efficiency and equipment operation stability can be enhanced.



Specification:

MODEL unit KFXRSG-69II
Factory Model Number   MDB-20HG
Applicable Ambient Temperature °C 0-43
Power Supply Specification / 380V3N-50HZ
Rated Heating Capacity kw 70
Nominal Input Power kw 19.2
Maximum Operating Current A 46
Hot Water Output L/H 760
Refrigerant / High-temperature dedicated type
Air Outlet Mode / Push out the wind
Protection Class / IPX4
Outlet Water Temperature / 28-60℃
Inlet and Outlet Port Type MM DN32
Noise DB(A) ≤55
Dimensions MM 1600*1100*1800
Weight KG 633



Advantages:The water and electricity separation design eliminates the risk of electric leakage. It uses low-GWP value environmentally friendly refrigerants, has no combustion process, and emits no waste gas or residue, meeting the green production standards. It has a wide range of applications, covering scenarios such as industrial drying, commercial heating, and agricultural breeding. The waste heat recovery function can replace traditional steam boilers and solve the problem of heat waste.
