One Feed PVC Plastic Water Supply Pipe Making Machine Full Intermeshing Engagement System
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
15 Days (1 - 1 Pieces) To Be Negotiated ( > 1 Pieces)
Brand:
Changyue
Product Description
PVC pipe production line / PVC tube making machine
Description of PVC pipe makign machine
PVC pipe extruder machine/UPVC pipe making machine is mainly used in the manufacturer of the UPVC and PVC pipes with various tube diameters and wall thickness such as agricultural and constructional plumbing, water supply and drain etc. This set is composed of conical twin-screw extruder,vacuum calibration tank, hual-off machine,cutter, stacker etc.
Our machine can produce the PVC pipe with diameter from 16-630mm.
Main parameter of PVC pipe making machine
Machine details ![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
Our customer&exhibition
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
![PVC Plastic Water Supply Pipe Making Machine]()
Packing
![PVC Plastic Water Supply Pipe Making Machine]()
Description of PVC pipe makign machine
PVC pipe extruder machine/UPVC pipe making machine is mainly used in the manufacturer of the UPVC and PVC pipes with various tube diameters and wall thickness such as agricultural and constructional plumbing, water supply and drain etc. This set is composed of conical twin-screw extruder,vacuum calibration tank, hual-off machine,cutter, stacker etc.
Our machine can produce the PVC pipe with diameter from 16-630mm.
Main parameter of PVC pipe making machine
| Model | pipe range(mm) | extruders | max.speed(m/min) | total power(kw) | max.output(kg/h) | line length(m) |
| PVC-50*2 | 16-50 | SJSZ51/105 | 6 | 60 | 150 | 20 |
| PVC-63 | 16-63 | SJSZ45/90 | 10 | 45 | 120 | 20 |
| PVC-110 | 50-110 | SJSZ51/105 | 6 | 60 | 150 | 24 |
| PVC-160 | 63-160 | SJSZ65/132 | 5 | 100 | 300 | 24 |
| PVC-250 | 110-250 | SJSZ80/156 | 3.5 | 120 | 400 | 28 |
| PVC-315 | 160-315 | SJSZ80/156 | 3 | 160 | 400 | 36 |
| PVC-450 | 250-450 | SJSZ92/188 | 1.5 | 200 | 700 | 36 |
| PVC-630 | 315-630 | SJSZ92/188 | 0.9 | 230 | 700 | 36 |
Machine details
300/600 hot cold mixer
Final material: PVC and additives mixed powder
Mixing type: Heating and cooling
Total Volume: 300/600L (heating/cooling)
Valid Volume: 225 / 360L (heating/cooling)
Rotation speed of stirring blade: 500/1000/100 r/min
Heating mode: Electricity/ self-friction
Mixing time: 6-10min
Cooling time: 10-15min
Final material: PVC and additives mixed powder
Mixing type: Heating and cooling
Total Volume: 300/600L (heating/cooling)
Valid Volume: 225 / 360L (heating/cooling)
Rotation speed of stirring blade: 500/1000/100 r/min
Heating mode: Electricity/ self-friction
Mixing time: 6-10min
Cooling time: 10-15min
SJSZ 65/132 twin conical screw extruder
screw & barrel: model: SJSZ-65/132 screw
main motor: 37 kw
extruder output : 250 kg/h
feedere: double screw feeder
vacuum pump power: 3 kw
inverter brand: Delta / ABB
electrical parts: Siemens
screw & barrel: model: SJSZ-65/132 screw
main motor: 37 kw
extruder output : 250 kg/h
feedere: double screw feeder
vacuum pump power: 3 kw
inverter brand: Delta / ABB
electrical parts: Siemens
PVC pipe mould
PVC pipe size: 50-200 mm
heater: ceramic heater
PVC pipe size: 50-200 mm
heater: ceramic heater
vacuum tank:
length: 6m
vacuum pump power: 4kw x 2
water pump power: 4 kw
water level control: automatic control
movement distance: 600 mm
movement motor power: 1.1 kw
length: 6m
vacuum pump power: 4kw x 2
water pump power: 4 kw
water level control: automatic control
movement distance: 600 mm
movement motor power: 1.1 kw
3 - claw haul off machine
inverter brand: ABB / Delta
electical parts: Siemens
inverter brand: ABB / Delta
electical parts: Siemens
non dust cutter
cutting range: 50-200 mm
cutting range: 50-200 mm
fiber laser printer
