TR Solids Control Jet Mud Mixer for Drilling Fluid Preparation

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: Negotiable

Brand: TR Solids Control

Product Description

TR Solids Control Jet Mud Mixer for Drilling Fluid Preparation

Main Introduction

Purpose: The Jet Mud Mixer from TR Solids Control is designed for reliable drilling fluid preparation and weighting in solids control systems, ideal for oilfield and HDD applications.
Function: It evenly mixes bentonite, barite, and additives with base mud to adjust fluid density, viscosity, and other properties, meeting wellsite requirements.
Working Principle: A centrifugal pump drives high-speed flow through the venturi hopper, creating negative pressure to draw in dry materials for fast hydration and uniform mixing, reducing manual work.

Why Choose TR Jet Mud Mixer ?

Benefits: Delivers stable, consistent drilling fluid, improving cuttings removal and preventing unstable wellbore conditions.
Design & Durability: Skid-mounted for easy installation and mobility; built with heavy-duty construction to withstand harsh environments.
Range of Models: Available in configurations with flow rates from 60 m³/h to 240 m³/h, suitable for small HDD projects to full-scale oilfield rigs.
Specifications: Clear options for matching pump power, hopper size, and nozzle diameter, with compact design to save rig space.
Advantage: Part of a full line of solids control equipment built for real field demands, making drilling operations smoother and more efficient.

Parameters of Our Jet Mud Mixer

Model	Capacity	Matching Pump	Motor Power	Work Pressure	Inlet Diameter	Nozzle Diameter	Hopper Dimension	Burden Speed	Weight	Dimensions
TRSLH150-50	240m³/h	TRSB8×6-13J	55kW	0.25~0.4MPa	150mm	50mm	750×750mm	≤100kg/min	1600kg	2200×1700×1200mm
TRSLH150-40	180m³/h	TRSB6×5-13J	45kW	0.25~0.4MPa	150mm	40mm	750×750mm	≤80kg/min	1450kg	2200×1700×1200mm
TRSLH150-30	120m³/h	TRSB5×4-14J	37kW	0.25~0.4MPa	150mm	30mm	600×600mm	≤60kg/min	1300kg	2000×1650×1100mm
TRSLH100	60m³/h	TRSB4×3-11J	11kW	0.25~0.4MPa	100mm	25mm	500×500mm	≤40kg/min	1100kg	2000×1650×1100mm

Competitive Advantages

1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.

Company Tenet

Customer's satisfaction is the highest pursuit of TR Solids Control.
