Low Loss Optical PLC Splitter 1xN 2xN PLC Splitter For FTTX / PON

Price Negotiable

Price: Negotiable

MOQ: 1pieces

Delivery Time: 5-8 work days

Brand: Gracyfiber

Product Description

Optical PLC Splitter Manufacturer | 1xN & 2xN PLC Splitters For FTTX/PON | Gracyfiber

1. Product Overview

Gracyfiber Optical PLC Splitters provide low-loss, high-uniformity optical power splitting for passive fiber optic networks.

2. Product Features

1xN PLC Splitters:

Parameter	1×2	1×4	1×8	1×16	1×32	1×64
Operating Wavelength	1260～1650nm
Insertion Loss(dB)	3.8	7.1	10.2	13.5	16.6	20.1
Uniformity(dB)	0.6	0.6	0.8	1.2	1.5	2
PDL(dB)	0.2	0.2	0.2	0.3	0.3	0.4
Directivity (dB)	55	55	55	55	55	55
Return Loss	≥50 dB (PC/UPC)
Fiber Type	ITU-T G.657.A or Customized
Fiber Length	Customized
Operating Temperature	-40 ～ +85°C
Storage Temperature	-40 ～ +85°C

2xN PLC Splitters:

Parameter	2×2	2×4	2×8	2×16	2×32	2×64
Operating Wavelength	1260～1650nm
Insertion Loss(dB)	4.1	7.4	10.6	13.9	17.1	20.4
Uniformity(dB)	0.8	0.8	1.2	1.5	2	2.5
PDL(dB)	0.3	0.3	0.3	0.4	0.4	0.4
Directivity (dB)	55	55	55	55	55	55
Return Loss	≥50 dB (PC/UPC), ≥55 dB (APC / No Connector)
Fiber Type	G.657.A or Customized
Fiber Length	Customized
Operating Temperature	-40 ～ +85°C
Storage Temperature	-40 ～ +85°C

Notes:

All parameters are tested at 1310 nm & 1550 nm and room temperature.
IL values are excluding connector loss.
If connectors are included: +0.3 dB per pair for PC/UPC types, +0.4 dB per pair for APC types

Low Insertion Loss

Excellent IL Uniformity

Low Polarization Dependent Loss

Wide Operating Wavelength Range

High Reliability

Flexible Packaging Options

Connector and Fiber Customization

3.Applications
