ASTM D6413 CFR 1615/1616 Vertical Burning Tester for Textiles
Price:
USD2700-3200/set
MOQ:
1 set
Delivery Time:
30 days
Brand:
GOLD
Product Description
ASTM D6413 CFR 1615/1616 Vertical Burning Tester for Textiles
This textile vertical burning tester is designed and manufactured according to relevant standards such as CFR 1615/1616, CA TB117, and ASTM D6413. It is primarily used to assess the flame retardancy of children's pajamas or pajama fabrics when exposed to a small open flame.
Compliance Standards
- ASTM D6413
- CFR 1615/1616 Children's Pajamas
- CA TB117 US Flame Retardant Standard for Upholstered Furniture Fabrics and Fillings
- GB/T 5455 Vertical Burning Test
Technical Parameters
| Parameter | Specification |
|---|---|
| Standard | ASTM D 6413, CFR 1615/1616 |
| Sample size | 356mm x 51mm |
| Igniter timing | 0~99.99 seconds |
| Accuracy | +0.01 seconds |
| Power | AC220V, 50Hz, 50W |
Key Features
- Painted chamber with a transparent observation window
- Internal dimensions: 329mm (L) x 329mm (W) x 767mm (H)
- Electronic automatic ignition system
- Automatic burner timing and positioning
- Adjustable ignition time (0-99.99 seconds) with digital display
- Adjustable flame height with optional temperature measurement
- Push-pull sample holder fixing device
- Sliding track mounted burner for easy operation
- Multiple sample holder options available
Technical Specifications
Sample size: Textiles: 80mm * 300mm
Burner motor power: 10W
Ignition timer: 0～99.99 seconds (standard 12 seconds)
Timer accuracy: ±0.01 seconds
Flame height measurement: Scale height 40mm
Operating gas: Methane, propane, butane, or other flammable gases
Power supply: AC220V, 50Hz, 50W
Weight: Approximately 20kg
