2.5mm Fluorocarbon-Coated Bronze Textured Concave-Convex Aluminum Single Panel
Price:
USD15.7/m2
MOQ:
1*20"container
Delivery Time:
15-20days
Brand:
TianYuan
Product Description
2.5mm Fluorocarbon-Coated Bronze Textured Concave-Convex Aluminum Single Panel
The 2.5mm Fluorocarbon-Coated Antique Bronze Textured Concave-Convex Aluminum Veneer is a high-performance architectural decorative material. It is manufactured using 2.5mm-thick aluminum alloy sheets (typically 3003 series, H24 temper) as the base material, formed into 3D concave-convex textures through CNC bending, molding, or etching processes, and finished with advanced fluorocarbon spraying technology incorporating a special antique bronze formula for premium architectural applications.
Core Features & Advantages
Material Advantages
- Lightweight & High-Strength: Density of 2.7g/cm³, weighing only ~6.8kg/m², with tensile strength of 100-280N/mm². Reduces building load while ensuring structural stability.
- Superior Weather Resistance: Fluorocarbon coating resists UV radiation, acid rain, and salt spray corrosion, maintaining colorfastness for 20-25 years outdoors.
- Fire Safety: Non-combustible aluminum base meets global building fire safety standards.
- Eco-Friendly & Recyclable: 100% recyclable, aligning with green building initiatives.
Texture & Aesthetic Highlights
- 3D Layered Effect: Concave-convex textures create unique light and shadow interactions, enhancing the visual impact of building facades.
- Antique Bronze Charm: Warm brown tones with metallic luster replicate the elegance of real copper at only 1/5 the cost.
- Smooth Tactile Finish: Fluorocarbon coating offers a sleek, non-glare surface for comfortable visual experience.
Craftsmanship & Performance
- Multi-Coat Protection: Adopts "three-coat two-bake" process (primer + antique bronze topcoat + clear coat) to form a composite protective film ≥40μm thick.
- Extreme Environment Adaptability: Stable performance from -50℃ to 80℃ without deformation or discoloration.
- Self-Cleaning Function: Low surface tension of fluorocarbon coating prevents dirt accumulation; rainwater rinsing restores cleanliness.
Manufacturing Process Details
- Material Selection & Pre-Treatment: High-quality 3003/H24 aluminum alloy sheets undergo cleaning and chromate treatment to enhance coating adhesion.
- Concave-Convex Forming (Optional Methods):
- Die Stamping: Specialized molds create regular or irregular embossed textures.
- CNC Bending: Precision CNC equipment bends sheets to form 3D geometric shapes.
- Etching/Engraving: Chemical etching or mechanical engraving creates embossed effects with recessed patterns.
- Surface Treatment:
- Primer: Epoxy primer for enhanced adhesion.
- Antique Bronze Topcoat: Fluorocarbon paint with special metallic pigments to simulate copper color and texture.
- Clear Coat: High-weather-resistant transparent coating for improved gloss and protection.
- Curing: High-temperature baking at 230℃ ensures firm bonding between coating and base material.
Key Technical Specifications
| Parameter | Value | Description |
|---|---|---|
| Thickness | 2.5mm | Balances strength and lightweight design |
| Material | 3003/1100 Aluminum Alloy | H24 temper, tensile strength ≥150MPa |
| Size Range | Max. 8000×1800mm | Custom sizes available |
| Coating Thickness | ≥40μm (three-coat) | Ensures long-term weather resistance |
| Weight | ~6.8kg/m² | Lightweight for easy installation |
| Service Life | 20-25 Years (Outdoor) | Outperforms conventional decorative materials |
Application Scenarios
Commercial Buildings
- High-End Shopping Mall Facades: Antique bronze texture elevates luxury appeal.
- Hotel Entrances & Curtain Walls: 3D concave-convex design creates distinctive entry landmarks.
- Office Building Exteriors: Combines modernity with timeless charm to showcase corporate strength.
Cultural & Public Buildings
- Museums & Art Galleries: Retro tones blend with contemporary design to complement cultural atmospheres.
- Libraries: Calm texture fosters a quiet environment; concave-convex structure enhances acoustic performance.
Residential Buildings
- High-End Apartment Facades: Enhances property value with unique aesthetics.
- Villa Exteriors & Decorative Trim: Customizable designs reflect personal taste.
Other Applications
- Billboards & Signage Systems: 3D effects boost visual communication.
- Elevator Door Frames & Interiors: Improves space texture and ease of cleaning.
- Architectural Sunshade Systems: Concave-convex structure provides effective shading while maintaining ventilation.
Installation & Maintenance
Installation Methods
- Caulked Joint Installation: 5-10mm gaps between panels filled with sealant to accommodate thermal expansion.
- Steel Frame Fixing: Bolted to welded angle iron or square tube frames.
- Concealed Frame Installation: Suitable for ceilings; panel edges fit into keel systems with no visible fasteners.
Maintenance Guidelines
- Daily Cleaning: Wipe with clean water or neutral detergent to maintain surface shine.
- Regular Inspections: Check connections annually to ensure structural safety.
- Special Stain Removal: Use dedicated fluorocarbon coating cleaners; avoid sharp tools to prevent scratches.
The 2.5mm Fluorocarbon-Coated Antique Bronze Textured Concave-Convex Aluminum Veneer is an ideal choice for modern architectural decoration, perfectly balancing aesthetic expression and practical functionality. It not only adds a classic and elegant charm to buildings but also offers long-lasting durability and easy maintenance, making it suitable for various high-end construction projects.
