24 Port Network Switch with Full-Duplex & Half-Duplex Communication LACP and SNMP Support
C9200L-24P-4G-A Specifications |
|
| Performance specifications | |
| Virtual Networks | 1 |
| Stacking bandwidth | 80 Gbps |
| Total number of MAC addresses | 16,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 11,000 (8,000 direct routes and 3,000 indirect routes) |
| IPv4 routing entries | 3,000 |
| IPv6 routing entries | 1,500 |
| Multicast routing scale | 1,000 |
| QoS scale entries | 1,000 |
| ACL scale entries | 1,500 |
| Packet buffer per SKU | 6 MB buffers for 24 or 48-port Gigabit Ethernet models, 12 MB buffers for 24 or 48-port multigigabit models |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24 and 48-port Gigabit Ethernet models, 32,000 flows on 24 or 48-port multigigabit models |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 4096 |
| PVST Instances | 128 |
| STP Virtual Ports (Port *VLANs) for PVST |
13,000 |
| STP Virtual Ports (Port *VLANs) for MST |
13,000 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo frames | 9198 bytes |
| Wireless bandwidth per switch | N/A |
| IP SGT binding scale | 10K |
| Number of IPv4 bindings | 10K |
| Number of SGT/DGT policies | 2K |
| Number of SXP Sessions | 200 |
| Bandwidth specifications | |
| Switching capacity | 56 Gbps |
| Switch capacity with Stacking | 136 Gbps |
| Forwarding rate | 41.67 Mpps |
| Forwarding rate with Stacking | 101 Mpps |
| Chassis Dimensions | 1.73 x 17.5 x 11.3 Inches |
| Weight | 10.38 Pounds |
| Mean time between failures (hours) | 392,210 |
