Nylon Fabric Coal Mine Conveyor Belts Industrial Grade For Bulk Material Conveyor System
Nylon Fabric Coal Mine Conveyor Belts For Bulk Material Conveyor System
Product Description
EP Nylon fabric Core Rubber Conveyor belts offer an optimal balance of strength, low stretch, durability, and cost-effectiveness, making them the most widely used type of synthetic conveyor belt for general and heavy-duty bulk material handling worldwide. Their robust construction from polyester and polyamide fabrics ensures reliable performance under demanding conditions.
| Belt Type | Fabric type | Fabric Thickness | Rubber Cover Thickness | Width (mm) |
Length (M) |
|
| Top(mm) | Bottom(mm) | |||||
| EP Belt | EP-100 | 0.75 | 2-8 | 0-5 | 300-2500 | <=300 |
| EP-150 | 0.85 | |||||
| EP-200 | 0.90 | 500-2500 | ||||
| EP-250 | 1.15 | |||||
| EP-300 | 1.25 | |||||
| EP-400 | 1.45 | 600-2500 | ||||
| EP-500 | 1.55 | |||||
| Belt Type | Fabric type | Fabric Thickness | Rubber Cover Thickness | Width (mm) |
Length (M) |
|
| Top(mm) | Bottom(mm) | |||||
| NN Belt | NN-100 | 0.75 | 2.5-8 | 0-5.5 | 400-2500 | <=300 |
| NN-150 | 0.8 | |||||
| NN-200 | 0.9 | 500-2500 | ||||
| NN-250 | 1.15 | |||||
| NN-300 | 1.25 | |||||
| NN-400 | 1.45 | 800-2500 | ||||
| NN-500 | 1.55 | |||||
Types of Rubber Conveyor Belts:
1. General Purpose Belts: Used for transporting bulk materials like grains, sand, and gravel.
2. Heat Resistant Belts: Designed to withstand high temperatures, often used in industries like cement and steel manufacturing.
3. Oil Resistant Belts: Made from special rubber compounds to resist oil and grease, commonly used in automotive and machinery industries.
4. Chemical Resistant Belts: Designed to resist exposure to chemicals, used in chemical processing and pharmaceutical industries.
5. Fire Resistant Belts: Used in environments where there is a risk of fire, such as mining and power plants.
6. Food Grade Belts: Made from materials that are safe for contact with food, used in the food processing industry.
EP belts are versatile and used across numerous industries for transporting bulk materials like:
1. Mining (coal, ore, aggregates)
2. Quarrying and cement production
3. Port and ship loading/unloading
4. Power plants
5. Agriculture (grain, fertilizer)
6. Packaging and distribution centers
Standard:
| Rubber Cover Grade | Tensile Strength (Mpa) | Elongation at break (%) | Abrasion (mm3) |
| H | 24.0 | 450 | 120 |
| D | 18.0 | 400 | 100 |
| L | 15.0 | 350 | 200 |
| Standards | Cover Rubber | Adhesion | ||||
| Tensile Strength | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
| DIN22102 | Mpa | % | mm3 | N/mm (≤1.5mm) |
N/mm (>1.5mm) |
N/mm |
| DIN 22102-Z | 15 | 350 | 250 | 3.5 | 4.5 | 5 |
| DIN 22102-W | 18 | 400 | 90 | 3.5 | 4.5 | 5 |
| DIN 22102-Y | 20 | 400 | 150 | 3.5 | 4.5 | 5 |
| DIN 22102-X | 25 | 450 | 120 | 3.5 | 4.5 | 5 |
| Standards | Cover Rubber | Adhesion | ||||
| Tensile Strength | Elongation at break | Abrasion | Cover to Ply | Cover to Ply | Ply to Ply | |
| AS 1332 | Mpa | % | mm3 | N/mm (≤1.9mm) |
N/mm (>1.9mm) |
N/mm |
| AS 1332-N17 | 17 | 400 | 200 | 4 | 4.8 | 6 |
| AS 1332-M24 | 24 | 450 | 125 | 4 | 4.8 | 6 |
We also could offer belt with cover grade in accordance to International standard such as DIN 22102, RMA, AS 1332, SABS 1173/2000, IS 1891, BS 490, JIS K 6322, etc
