PHC Concrete Pile Foundation Equipment
Pile Foundation Equipment For PHC Concrete Pile Hydraulic Static Pile Driver
VY series hydraulic statics pile driver is a new environmentally friendly pile foundation construction equipment with a number of national patents.
VY series hydraulic static pile driver has more than 10 varieties, the pressure capacity from 60 tons to 1200 tons. Using high quality materials and components, adopting the unique hydraulic piling design and processing methods ensures the clean and highly reliability of hydraulic system. High quality is guaranteed from the headstream. We provide the best service and personalized design with the concept “All for the customers”.
Main Technical Parameter
| Parameter | VY128A | |
| Max.piling pressure(tf) | 128 | |
Max.piling speed(m/min) |
Max | 6.9 |
| Min | 1.9 | |
| Piling stroke(m) | 1.6 | |
Move stroke(m) |
Longitudinal Pace | 1.6 |
| Horizontal Pace | 0.4 | |
| Slewing angle(°) | 12 | |
| Rise stroke(mm) | 1580 | |
Pile type (mm) |
Square pile | F200-F350 |
| Round pile | Ф200-Ф350 | |
| Min.Side Pile Distance(mm) | 390 | |
| Min.Corner Pile Distance(mm) | 1100 | |
Crane |
Max.hoist weight(t) |
8 |
| Max.pile length(m) | 13 | |
Power(kW) |
Main engine | 45 |
| Crane engine | 22 | |
Overall dimension(mm) |
Work length | 8000 |
| Work width | 4110 | |
| Transportation height | 3250 | |
| Total weight(t) | 130 | |
FAQ:
Q1. What is your terms of payment?
Ans.: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q2. What is your terms of delivery?
Ans.: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
Ans.: Generally, it will take 7 -10 working days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.
Q4. What is the warranty of our machine?
Ans.:Our main machine enjoys a 1 year warranty, during this time all accessories broken can be changed for a new one. And
weprovide videos for machine install and operation.
Q5. What is your terms of packing?
Ans.: Generally, we use standard exported wooden case for LCL goods, and fixed well for FCL goods.
Q6. Do you test all your goods before delivery?
Ans.: Yes, we have 100% test before delivery.And we will attach our inspect report for every machine.
- Packaging Details
- Standard export package
- Port
- Shanghai Tianjin
- Lead Time :
-
Quantity(Sets) 1 - 1 >1 Est. Time(days) 5 To be negotiated
