Fiber Optic connector SC pc/upc singlemode simplex 2.0mm RohS material blue housing
Fiber Optic connector SC pc/upc singlemode simplex 2.0mm RohS material blue housing
Description:
SC fiber connector is snap-in connector also with a 2.5mm ferrule that is widely used for its excellent performance.
Feature:
- Low insertion loss and return loss
- Free-floating ceramic ferrule
- UL-rated plastic housing and boot
- Boots in a variety of colors
- High precision alignment
Mechanical Drawings:
Specifications:
|
Item |
Single mode |
Multi mode |
|
Insertion loss |
PC≤0.20dB, UPC ≤0.25dB, APC ≤0.25dB |
＜0.3dB |
|
Return loss |
PC ≥50 dB, UPC ≥55 dB & APC ≥60 dB |
＞25dB |
|
Insert-pull test |
1000(times) ＜0.2dB |
|
|
Operating temperature |
-40℃~ +80℃ |
|
|
Ceramic ferrule spec |
125.5um concentricity deviations: ＜1um |
127um concentricity deviations: ＜3um |
|
Suitable fiber |
PC/APC(9/125um) |
PC(50/125um, 62.5/125um) |
Application:
1. CATV, metro test equipment;
2. Telecommunication networks; 3. Local area networks (LAN); 4. Wide area networks (WAN); 5. Premise installations; 6. Data processing networks; 7. Video and military active devicetermination.
8.Optical Distribution Frame
9. Optical Network Equipments
