High Power Cell Phone Signal Repeater 1800MHz , 1805 - 1880MHz Downlink

Price Negotiable

Price: Negotiable

MOQ: 1PC

Delivery Time: 1-3 working days

Brand: EST

Product Description

High Power Cell Phone Signal Repeater 1800MHz , 1805 - 1880MHz Downlink

1 Quick details :

1 Uplink:1710~1785MHz Downlink 1805~1880MHz

2 Coverage area : 1000m2

3 Function :1. Enhance Mobile Phone Signal Strength

4 easy installation & operation

5 Build-in Power Supply

2 Brief description

The device featured by easy installation & operation and no interference. It is the ideal device for boost mobile phone signal. A mobile phone repeater could also improve indoor ctromagnetism environments, protract cellular battery life and reduce radiation of cellphones.

3 Technique

Frequency range	Uplink:1710~1785MHz Downlink 1805~1880MHz
Gain ( dB)	Uplink Gp≥60 Downlink Gp≥65
Export power (Po)	≥27dBm
Pass band ripple	≤3dB
I/O impedance	50Ω/N connector
Noise figure	≤4dB
Transmission Delay	≤0.5μs
Ambient temperature	-10℃～60℃
Power supply	AC110～240V 45～55Hz
Size	220 x180 x 20 mm
Reliability	To the GB6993-86 standard
Electromagnetic compatibility	To the ETS300 694-4 standard
Function	a) Power supply LED denote b) Export power LED denote
coverage area	1000 m2

4 product warranty

· free replacement for first three months ( our company pay the shipping cost )

· The warranty period is 3 years. ( shipping cost under customer's expenses)

· lifetime warranty :1,no big damage to the product;2,shipping cost under customer's expenses;3, Only charge for material cost depending on the specific condition ( case by case)
