Wireline Core Drill Parts BQ NQ HQ PQ AQU BQU NQU Ezy Lock


Description :


Ezy Lock Overshot

Overshot is a necessary device in wireline drilling. It's dropped on a cable and directly couples onto and lift up the inner tube assembly, eliminating the need to couple and uncouple the rod string each time the core is retrieved.

Ezy Lock Overshot is a modified product based on compact overshot. It protects against accidental release of the core barrel. This is ideal for suface application when hoisting above ground.

Features:

 •  Ezy Lock Sleeve provides a quick, one-handed rotation of the sleeve to lock the lifting dogs.

 •  Quick Release Safety Pin locks the overshot head to the spearhead point.

Specifications

1. A necesary device in wireline drilling
2. Lifts up the inner tube assembly directly


Parts Description:





As a professional manufacturer of Q series overshot assembly in China, we still provide customers worldwide with China overshot assembly, hoisting plug, foot clamp, circle wrench, etc.

If you're interested in our Q series overshot assembly, please contact us freely.

1. Drill rod: BQ, NQ, HQ, PQ and AW, BW, NW, HW, BTW, NTW
    Casing tube: BW, NW, HW, HWT

2. Core barrel: BQ NQ  NQ3 HQ HQ3 PQ PQ3  & head assembly and assembly

3.  BQ, NQ, HQ, PQ, BTW, NTW, HTW  etc. Diamond core bit, reaming shell & shoe bit (syn. and surface-set, PDC) , oversize supplied

4. Drill tool: hoisting plug, water swivel, overshot, outer tube & inner tube wrench, foot clamp,etc.
