Integrated Steel Hard Rock, Stone Jaw Crusher Machine For Mine, Smelting PE250 * 400 Broken Cavity
Integrated Steel Hard Rock, Stone Jaw Crusher Machine For Mine, Smelting PE250*400 Broken Cavity
|
PE SERIES CRUSHER TECHNICAL DATA(coarse crushing) |
||||||||
|
model |
feed opening size (mmxmm) |
max feed edge (mm) |
discharge opening range (mm) |
processing capacity (t/h) |
eccentric shaft speed (r/min) |
motor power (kw) |
weight (t) |
overall dimensions LxWxH(mm) |
|
PE250x400 |
250x400 |
210 |
20-60 |
4-14 |
300 |
15 |
2.8 |
1450x1315x1296 |
|
PE400x600 |
400x600 |
340 |
40-100 |
10-34 |
275 |
30 |
6.4 |
1565x1732x1586 |
|
PE500x750 |
500x750 |
425 |
50-100 |
20-52 |
275 |
55 |
10.3 |
1890x1916x1870 |
|
PE600x900 |
600x900 |
510 |
65-160 |
45-80 |
250 |
75 |
16.8 |
2305x1840x2298 |
|
PE750x1060 |
750x1060 |
630 |
80-140 |
72-130 |
250 |
110 |
24.5 |
2560x2472x2840 |
|
PE250x500 |
250x500 |
240 |
25-75 |
8-25 |
300 |
22 |
3.5 |
1235x1475x1398 |
|
PE800x1060 |
800x1060 |
640 |
100-200 |
136-230 |
250 |
110 |
29 |
2500x2472x2840 |
|
PE870x1060 |
870x1060 |
660 |
200-260 |
190-336 |
250 |
110 |
30.5 |
2870x2430x2800 |
|
PE900x1200 |
900x1200 |
750 |
120-240 |
180-280 |
200 |
132 |
46.5 |
3435x2904x2990 |
|
PE1000x1200 |
1000x1200 |
850 |
220-340 |
200-300 |
200 |
132 |
47 |
3535x2904x2990 |
|
PE1200x1500 |
1200x1500 |
1000 |
150-300 |
300-500 |
180 |
200 |
79 |
4587x3342x3553 |
|
PE1500x1800 |
1500x1800 |
1200 |
220-350 |
500-800 |
180 |
280 |
122 |
5160x3660x4248 |
|
(PEX SERIES CRUSHER TECHNICAL DATA(fine crushing) |
||||||||
|
model |
feed opening size (mmxmm) |
max feed edge (mm) |
discharge opening range (mm) |
processing capacity (t/h) |
eccentric shaft speed (r/min) |
motor power (kw) |
weight (t) |
overall dimensions LxWxH(mm) |
|
PEX150x750 |
150x750 |
120 |
18-48 |
5-16 |
320 |
15 |
3.5 |
1380x1658x1025 |
|
PEX250x750 |
250x750 |
210 |
25-60 |
8-22 |
330 |
22 |
4.9 |
1545x1667x1330 |
|
PEX250x1000 |
250x1000 |
210 |
25-60 |
10-32 |
330 |
30-37 |
6.5 |
1530x1992x1380 |
|
PEX250x1200 |
250x1200 |
210 |
25-60 |
13-38 |
330 |
37 |
7.7 |
1720x2130x1430 |
|
PEX350x750 |
350x750 |
300 |
15-50 |
16-35 |
300 |
37 |
6.5 |
1530x1880x1595 |
|
PEX300x1300 |
300x1300 |
250 |
25-80 |
20-70 |
300 |
75 |
11.6 |
1800x2320x1730 |
|
PEX350x1200 |
350x1200 |
300 |
70-140 |
20-120 |
300 |
75 |
11.43 |
2123x2250x1721 |
Technical parameters for hammer crusher:
|
Name |
Model |
Max feed size (mm) |
Handling capacity (t/h) |
Power of motor (kW) |
Weight (t) |
|
|
PC400×300 |
30 |
5-8 |
11 |
1.5 |
|
PC600×400 |
100 |
10-15 |
18.5 |
3 |
|
|
PC800×600 |
150 |
20-25 |
55 |
7 |
|
|
PC800×1000 |
280 |
20-50 |
110 |
12 |
|
|
Circuit Type |
PCH0606 |
200 |
18-30 |
30 |
17 |
|
PCH0808 |
250 |
30-50 |
45 |
29 |
|
|
PCH1010 |
300 |
45-80 |
90 |
52 |
Applications:
The base of bearing use of integrated steel structures;-The broken cavity is deep and without dead zone, increased capacity and output feed;-The outlet use of pad-style adjustment devices, convenient and reliable, large of adjustment range, and increase the flexibility of the equipment;-Low noise, less dust.
Competitive Advantage:
This series of products have many advantages, such as big reduction ratio, equal product granularity, simple structure, reliable working condition, convenient repair and economical operation. They are widely used in the works of mine, smelting, building material, road, railway, irrigation, chemical industry, etc. The compression strength of the materials to be crushed is less than 320MPA.
