YGJ Series Roller Mill Pulveriser Machine For Cocoa Beans
YGJ Series 250 kg-1850KG 0.75 kw-11KW Advanced Level Roller Mill Pulveriser Machine For Oil Materials
Main Application :
The machine is used to grind the materials which have oil such as sesame, peanut and almond. The machine is well designed and developed by our company, it is filled a gap in the oil mill, which had reached the international advanced level.
Working principle :
The raw materials are into the roller area from hopper, they are milled into powder by the squeezed of the rollers. You can get different size of final production by adjusting the distance of two rollers. The machine has some advantages of easy operation, low noise and high capacity which is the best mill for oil materials.
Technical Parameters :
| Model | Prdouction Capacity | Crushing Fineness | Motor Power | overall dimension | weight |
|---|---|---|---|---|---|
| YGJ1-100 | 20-80 kg/h | 8-20 mesh | 0.75 kw | 500*500*890 mm | 250 kg |
| YGJ2-100 | 20-80 kg/h | 8-40 mesh | 1.5 kw | 500*500*1130 mm | 300 kg |
| YGJ3-100 | 20-80 kg/h | 8-60 mesh | 2.2 kw | 500*500*1370 mm | 350 kg |
| YGJ4-100 | 20-80 kg/h | 8-80 mesh | 3 kw | 500*500*1610 mm | 400 kg |
| YGJ1-150 | 50-200 kg/h | 8-20 mesh | 2.2 kw | 720*520*920 mm | 500 kg |
| YGJ2-150 | 50-200 kg/h | 8-40 mesh | 3 kw | 720*520*1160 mm | 550 kg |
| YGJ3-150 | 50-200 kg/h | 8-60 mesh | 4 kw | 720*520*1160 mm | 600 kg |
| YGJ4-150 | 50-200 kg/h | 8-80 mesh | 5.5 kw | 720*520*1640 mm | 650 kg |
| YGJ1-300 | 100-500 kg/h | 8-20 mesh | 3 kw | 920*700*1200 mm | 760 kg |
| YGJ2-300 | 100-500 kg/h | 8-40 mesh | 4 kw | 920*700*1480 mm | 940 kg |
| YGJ3-300 | 100-500 kg/h | 8-60 mesh | 7.5 kw | 920*700*1760 mm | 1120 kg |
| YGJ4-300 | 100-500 kg/h | 8-80mesh | 7.5 kw | 900*700*2060 mm | 1300 kg |
| YGJ1-500 | 200-1000 kg/h | 8-20 mesh | 5.5 kw | 1100*730*1220 mm | 950 kg |
| YGJ2-500 | 200-1000 kg/h | 8-40 mesh | 7.5 kw | 1100*730*1480 mm | 1250 kg |
| YGJ3-500 | 200-1000 kg/h | 8-60 mesh | 11 kw | 1100*730*1820 mm | 1550 kg |
| YGJ4-500 | 200-1000 kg/h | 8-80 mesh | 11 kw | 1100*730*2120 mm | 1850 kg |
