SZG Series Double Cone Rotary Vacuum Drier And Mixer
Main Application :
Its mainly used for drying and mixing of material in pharmaceutica chemical and foodstuff trades etc.
Working principle :
This machine has good drying and mixing effect to heat sensitive, easy oxidizing and non-crystalline damage material, solvent recovering material and strong irritating and toxic material. With high drying speed and uniform product drving, it has no pollution to the material and is operated and cleaned easily, in addition, the optimize designed seal has good sealing effect and convenient maintenance.
Technical Parameters :
|
Model |
Total |
Speed |
Power |
Loading |
Heating |
Working pressure |
Working temperature |
||
|
Innertank |
Jacket |
Innertank |
Jacket |
||||||
|
SZG-30 |
30L |
10r/min |
0.8kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-50 |
50L |
10r/min |
0.8kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-100 |
100L |
6.5r/min |
1.1kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-350 |
350L |
6.5r/min |
1.5kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-500 |
500L |
6.5r/min |
1.5kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-750 |
750L |
6.5r/min |
1.51kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-1000 |
1000L |
6.5r/min |
3kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-1500 |
1500L |
6.5r/min |
3kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-2000 |
2000L |
6r/min |
4kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-3000 |
3000L |
5r/min |
5.5kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
|
SZG-4000 |
4000L |
4r/min |
7.5kw |
≤50％ |
Steam,hot water |
0.8-0.1Mpa |
0.25-0.3Mpa |
≤80℃ |
≤140℃ |
Technical Parameters :
