DLH Series Cone Blender For Chemical Powder
Price:
Negotiable
MOQ:
1 set
Delivery Time:
30 days
Brand:
Hongda Powder
Product Description
Main Application :
As a new type high efficiency and high precision mixing equipment, this machine is widely used for mixing of powdery or paste materials in pharmaceutical, chemical and feed trades etc..
Working principle :
The machine consists of single screw and type S blade. It is featured with large agitating scope, high mixing speed, no dead angle. It is more suitable for mixing materials with a great disparity in specific weight and mixing proportion.
Technical Parameters :
| Model | Barrel volume | Max loading volume | Max loading weigh | Mixing time | Materialsize | Motor power | Overall dimension | Weight |
|---|---|---|---|---|---|---|---|---|
| DLH100 | 100L | 60L | 60kg | 0-99min | 20-350mesh | 2.2kw | ￠700*1400mm | 300kg |
| DHL200 | 200L | 120L | 120kg | 0-99min | 20-350mesh | 3kw | ￠890*1930mm | 600kg |
| DHL300 | 300L | 180L | 180kg | 0-99min | 20-350mesh | 3kw | ￠1010*1850mm | 600kg |
| DHL500 | 500L | 300L | 300kg | 0-99min | 20-350mesh | 4kw | ￠1180*2290mm | 800kg |
| DHL1000 | 1000L | 600L | 600kg | 0-99min | 20-350mesh | 5.5kw | ￠1500*2700mm | 1200kg |
| DHL2000 | 2000L | 1200L | 1200kg | 0-99min | 20-350mesh | 11kw | ￠1900*3500mm | 1800kg |
| DHL3000 | 3000L | 1800L | 1800kg | 0-99min | 20-350mesh | 15kw | ￠2120*4000mm | 2200kg |
| DHL4000 | 4000L | 2400L | 2400kg | 0-99min | 20-350mesh | 18.5kw | ￠2200*4050mm | 2600kg |
| DHL5000 | 5000L | 3000L | 3000kg | 0-99min | 20-350mesh | 22kw | ￠2530*4300mm | 3000kg |
| DHL6000 | 6000L | 3600L | 3600kg | 0-99min | 20-350mesh | 30kw | ￠2850*4780mm |
3500kg |
