No.

Item

General Parameter

Remark

1

Rated Capacity

9.0Ah

Standard discharge(0.2C₅)after standard charge(0.2C₅)

2

Minimal Capacity

8.5Ah

3

Nominal Voltage

36.0V

4

Cycle Life

Residual capacity is more than 60% of the rated capacity

◆Charge: CC@0.2C to 42.0V, then CV till current to 0.05 C₅

◆Rest: 30min.

◆Discharge: 0.2 C₅ to 30.0V

◆Temperature:20±5℃

◆Carry out 500 cycles

5

Discharge cut-off voltage

30.0V

30.0V (recommended)

6

Charging cut-off voltage

42.0V

42.0V (recommended)

7

Assembly method

INR18650EC-2.2AH

10S4P

8

Housing material

Aluminium alloy &ABS+PC

9

Standard charge

0.2 C₅ constant current (CC) charge to 42.0V,then constant voltage (CC)42.0V charge till charge current decline to ≤0.05 C₅

Charge time : Approx 7.0h

10

Standard discharge

Constant current 0.2 C₅

Cut-off voltage 30.0V

11

Maximum Charge Current

4.5A

2A recommended for better performance and life

12

Continuous Discharge Current

7.0A

Over current 50±10A (5ms~20ms)

13

Operation Temperature Range

Charge: 0~55℃

60±25%R.H.

Discharge: -10~60℃

14

Storage Temperature Range

Less than 1 year : 0~25℃

60±25%R.H.

at the shipment state

Less than 3 months:-5~35℃

15

Approx. Weight

Approx  3.0Kg

16

Dimension

Height: Approx 410.0mm

Diameter: Approx 98.0 mm

17

Short Circuit Protection

Will recover after recharge
