Cylindrical 3.2V LiFePO4 Battery LIR18650 1100mAh Power Type for High Power Devices
Cylindrical 3.2V LiFePO4 Battery LIR18650 1100mAh Power Type for High Power Devices
Features For Cylindrical 3.2V LiFePO4 Battery LIR18650 1100mAh Power Type for High Power Devices
- Excellent abuse tolerance and environmentally friendly with Reach and Rohs
- Excellent calendar life, 10X cycle life vs. conventional lithium ion , more than 2000 times base on DOD 80%
- High consistency in voltage capacity and resistence
- Suitable for a wide variety of applications and system designs.
- Proven performance in the toughest conditions, combining durability, reliability, and safety
- Offers an excellent combination of price-performance.
Application:
Portable high power devices power tool
Stationary battery backup systems pump
Grid stabilization energy storage system
Commercial truck and bus hybrid electric vehicles (HEVs)
BatterySpecification List:
| No. | Items | Specifications |
| 1 | Charge cut-off voltage | 3.65V |
| 2 | Nominal voltage | 3.2V |
| 3 | Minimal capacity | 1500mAh @ 0.2C Discharge |
| 4 | Nominal capacity | 1550mAh @ 0.2C Discharge |
| 5 | Charge current | 1C |
| 6 | Standard charging method | 1C CC (constant current) charge to 3.65V, then CV (constant voltage 3.65V) charge till charge current decline to £ 0.05C |
| 7 | Charging time | Standard charge: 2.0 hours Ref |
| 8 | Max. charge current | 10 C |
| 9 | Max. continue discharge current | 5A (Cell skin temperature cannot exceed 80°C) |
| 10 | Discharge cut-off voltage | 2.0V |
| 11 | Operating temperature |
Charging: -10°C ~ 45°C Discharging: -20°C ~ 60°C (Cell skin temperature cannot exceed 80°C) |
| 12 | Storage temperature/humidity |
Temperature -10°C ~ +35°C Humidity 65%±20%RH (Recommended to store 23 ± 5°C for long term storage) |
| 13 | Cell Weight | 42.0g±1.0g |
| 14 | Cell Dimension |
Length: 65.0±0.3 mm Width: 18.2±0.2 mm |
Interior Structure
Application Area
Storage Battery
The cell shall be storied within -10°C ~ 35°C range environmental conditions. If the cell has to be stored for a long time (Over 3 months), the environmental condition should be:
Temperature: 23 ± 5°C
Humidity: 65 ± 20%RH
The voltage for a long time storage shall be 3.3V ~ 3.4V range.
Similar Battery Photos
Power Tool Battery Pack made by 18650 high power cell
Package Detail
