Professional Auto Die Cutting Machine Can Print PVC Film / Copper / Foil
Price:
Negotiation
MOQ:
1 Set
Delivery Time:
30Works Dates
Brand:
Upperbond
Product Description
Professional Auto Die Cutting Machine Can Print PVC Film / Copper / Foil
INTRODUCTION
The machine adopted imported wiring,from bottom-upstructure,Laminated,die cutted,Feed-in.educate
waste materid cutting or rolling are controllrd by computer in one time.It include stamping function,photocell device.
FUNCTION
1. It is a the best machine which can be match with printing machine for making paper adhesive trademark terylene film trademark Radium trademark.
2. It can die cutting many kinds of dielectric and electric material such as:PVC,film,copper foil,Shots,aluminum foil Foam.
SPECIFICATION
| Model type | MQ320 | MQ420 | MQ570 |
| Die Cutting Speed | 30-180m/min | 30-180m/min | 30-150m/min |
| Max Feeding Diameter | 500mm | 500mm | 600mm |
| Max Web Width | 320mm | 420mm | 570mm |
| Max Die Cutting Width | 320mm | 42mm | 570mm |
| Max Die Cutting Length | 300mm | 400mm | 400mm |
| Positioning Precision | ±0.10mm | ±0.10mm | ±0.10mm |
| Main Motor Power | 2.2kw | 3kw | 4kw |
| Power Supply Voltage | 220v±10% | 220v±10% | 220v±10% |
| Weight | 1700KG | 2000KG | 3000KG |
| Dimension (mm) | 2800x950×1400 | 2800×1050×1400 | 3000×1250×1400 |
