0.35 - 0.7 MPa Hot Air Fluidized Cut Tobacco Drier Cigarette Production Machine

Price Negotiable

Price: Negotiation

MOQ: 1 Set

Delivery Time: 30Works Dates

Brand: UPPER BOND

Product Description

0.35 - 0.7 MPa Hot Air Fluidized Cut Tobacco Drier Cigarette Production Machine

Application and Features:

Hot air fluidized Cut stem drier is designed for cut stem expansion and drying, it combine with steam jet conditioning machine be used in Pilot cut-stem processing line.
The filling power of cut stem can be reached over 6cm³/g.
Cut stem is fluidized by Hot air during expanding and drying, whole process just needs 6 seconds.
The cut stem moisture content is adjustable.
Build in Cut-stem pneumatic classifier for separate stem slivers conveniently.
Special designed air heating system and structure, energy save.
Minimum space requirement, simple operation and easy maintains.

Technical Specifications:

Item	Unit
Output	kg/h	200-400
Drying period	s	6
Temperature of air	℃	150
Heat resource.		Steam
Moisture of cut stem at inlet	%	39
Moisture of cut stem at let-out	%	14±0.5
Steam consumption	Kg/h	350-700(0.7MPa)
Electrical	kw	18.5
Weight (approx)	kg	6000
Dimension	mm	8650mm×1240mm×5000mm
