ST Small Size and bulk Fiber Optic Attenuator 1 - 30db , Low Attenuation Error
ST Small Size and bulk Fiber Optic Attenuator 1 - 30db , Low Attenuation Error
Qucik Detail:
Model Number: ST
Color: metal
Polishing: PC/UPC/APC
Attenuation range: 0-30 dB
Connector: FC, SC, ST, LC, MU, etc
Specifications
1.Stable performance;
2.Low attenuation error,high return loss;
3.Bellcore standare
4,easy to operat
Features
1) High precision.
2) Good stability.
3) Small size and bulk.
4) Easy to operate.
5) Based on IEC/Telcordia Bell GR-326-Core Tested.
6) Optional adapter: SM/MM, Simplex/Duplex
7) 100% Optic test(Insertion loss ≤0.20dB)
Application
1 Fiber optic communication systems.
2 Fiber optic CATV
3 Fiber optic test
Specification
| Parameter | Value | Unit |
| Operating Wavelength | 1310/1550 ± 10 | nm |
| Tolerance for 1~5 dB Attenuation | ± 0.5 | dB |
| Tolerance for 6~30 dB Attenuation | ± 10 | % |
| Return Loss | > 50 | dB |
| Operating Temperature | -40 to +75 | C |
| Polarization Dependent Loss | < 0.1 | dB |
| Mating Durability | >1000 | cycle |
Competitive Advantage
DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, productsexported to Europe and the United States and Southeast Asian countries.
