Plastic 17.5KW Bottle Blowing Machine / Semi Automatic Blow Moulding Machine
Plastic 17.5KW Bottle Blowing Machine / Semi Automatic Blow Moulding Machine
Quick Detail:
- Condition: New
- Application: Bottle
- Plastic Processed: PET
- Blow Moulding Type: Stretch Blow Moulding
- Automatic: Yes
- Model Number: CM-8Y
Description:
1. Solenoid Valve (Pneumatic Valve for Mold Clamping): Korea, PMC
2. High Pressure Valve (Blowing Valve): China
3. Seal & Stretch Cylinder: China
4. Clamping Cylinder: China
5. PLC: Delta, Taiwan
Applications:
CM-8Y Semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 0.1L to 2L.
Specifications:
Model | ITEM |
| CM-8Y |
Container | Product material | / | PET |
Volume | L | 0.1-2 | |
Theoretical output | pcs/h | 1400-1800 | |
Preform length | mm | ≤350 | |
Preform inner diameter | mm | φ5-38 | |
Mould | Max.mould plate Diameter(L*W) | mm | 350*380 |
Max.mould thickness | mm | 180 | |
Clamping force | kn | 45 | |
Mould opening stroke | mm | 160 | |
Machine size and Weight | Main machine (L*W*H) | cm | 1600*600*1610 |
Main machine weight | kg | 500 | |
Heater (L* W*H) | cm | 1870*630*1450 | |
Heater weight | kg | 250 | |
Power | kw | 17.5 |
Competitive Advantage:
- Save Cost
- Stable Quality
- Save Place
