PE coated Paper Disposable Cup Making Machine 220v / 380v 50hz 3.8kw
Main technical parameter:
|
Model |
L12(3-12oz) |
|
production capacity |
45-55pcs/min |
|
required paper |
150-250gsm one side PE coated paper |
|
Detail cup sizes |
(A)50-90mm; (B)45-115mm; (C)35-64mm; (D)4.5-10mm |
|
Air supply requirement(provided by customer) |
working pressure:0.4-0.6Mpa gas volume:0.5m3/minute |
|
total power |
220v 50hz 3.8kw or 380v 50hz 3.8kw(variable-frequency control) |
|
weight |
1300kg |
|
overall dimensions |
2550×1260×1700m |
Advantages:
1. We use three rows of chain together with gear while other factories only have two rows of chain and triangle chain. In a way, it improves the high stability.
2. Aluminum block is not easy to combustion and performance in high safety. In addition it can save electricity. Our 3 turnplates are all aluminum while other factories only 1, remain 2 are iron
3.The main-frame of the machine is an incline. And the incline can help the cups easily drop into the plastic holes, the rate of which goes up.
4. The shape of the head is oblate, which can seal the cups easily. It is much better than that is round
