Stadium Outdoor Full Color Led Display Mobile Removing Rental Truck Panel
Stadium Outdoor Full Color Led Display Mobile Removing Rental Truck Panel
Specifications:
| duct model number | Mled-PH10-0 |
| 1.Pixel | |
| Pixel L ED | 3535 |
| Pixel Configuration | 1 R, 1G , 1B |
| Wave length ( nm ) | R: 800-1000 , G:2040-2450, B: 360-430 |
| Pixels Pitch ( mm ) | 10 |
| 2 . Module | |
| Module Size ( mm ) | 320 * 160 * 20 |
| Module Pixels (dot) | 32 *16 |
| 3.Unit box | |
| Module quantities in a unit box | 3 (L) * 6 ( H ) |
| Unit box size ( mm ) | |
| 960 (L) * 960 (H) * 180 | |
| Unit box Pixels ( dot ) | 96 * 96 |
| Unit box material | Aluminum or Iron |
| Unit box weight (kg) | Aluminum : 30 or Iron : 40 |
| 4.Packaging | |
| Packing Way | Two unit boxes packed into one |
| Packing box material | Wooden case or Flight box |
| Packing box size (mm) | 960 * 960 * 160 |
| 5.electricity parameter | |
| White Balance Brightness ( cd/m 2 ) | ≥ 7500 |
| Color temperature ( K ) | 5000-9500 (choice by user) |
| Brightness Adjusted | 100 grade by software or by Auto-optic induced. |
| View Angel | Horizontal 140 ° ; Vertical 120 ° |
| Best viewing distance ( m ) | 16-150 |
| Communication distance ( m ) | Internet Wire : 120 Fiber Cable : 1000 |
| Screen work Method | 1/2 |
| LED driving method | Constant driving current |
| Gray Grades | 16384 levels for each color |
| Display Color | 4 , 398 , 046 , 511 , 104 |
| Refresh Frequency ( Hz ) | ≥800 |
| Picture display method | Dots to dots display synchronized with CRT |
| Signal interface | DVI |
| Input signal | Video : PAL/NTSC optioned . VGA, Svideo, DVD, TV |
| Display format | 800 * 600 , 1024 * 768 , 1280 * 1024 |
| Software | Support windows series system |
| Protection grades | IP 65 |
| Working temperature (ºC ) | -30 +60 |
| Humidity ( RH ) | Up to 95 |
| Stored temperature ( ºC) | -30 +70 |
| Screen Lifetime(hours) | ≥100, 000 |
| Out of controlled dots | ≤3/10, 000 (Out of controlled dots means the pixels of which the brightness, |
| and the wave length are both >10% depart to the normal one) | |
| Whole display flatnes | Less than 1mm Juncture |
| Maintance way | Back-maintained or front-maintained, |
| modules displaced | |
| Switch power supply |
Switch power supply (include CE/GS or UL/CSA certificate) 110V/60HZ , 220V/50HZ |
| Power Consumption ( w /m 2 ) | Max : 1000 , Average: ≥ 480 |
Outdoor advertising video led digital Billboard:
1.RoHS and CE,ISO,UL
2.Waterproof IP65
3.High brightness.
4.Competitive price.
1.Applications:
outdoor full color digital billboard are very popular in LED display advertising field. This type digital billboards are widely used Outdoor plaza,Outdoor building,stadium,shopping mall,cross road,highway, airport etc;
2.Features :
Vivid and exact picture, minimum noise, advanced test equipment, support any pc operationsystem and play a variety of information like video, word, flash, music, clock, graph etc. LED billboard Cabinet design for easy install and dismantle
MELTON is always focus on the competitive price,High quality and Best services to each customer,our core value is "Quality Assurance,Lifetime Service" and guarantee to the customers: No Compaint.
At the same time,MELTON strives to benefit employees,shareholders and business partners.
We balance the short-term and long-term benefits to realize sustained development.
For our Customer: Good price,high quality products and 24hours services
For our Staff: Providing good sale enviroment and good welfare
For our Shareholder: Honest cooperation and double win.
For Society: Make the world bright,make the earth green.
