P5 Double Sides Taxi LED Display Outdoor / Full Color car top advertising signs
P5 Double Sides Taxi LED Display Outdoor / Full Color car top advertising signs
Specifications
| Numbers | Technical indexes | P5 Taxi Top LED Display |
| 1 | Pixel pitch | 5mm |
| 2 | Module size | 160mm× 160mm |
| 3 | Module resolution | 32× 32 |
| 4 | Module density | 40, 000dots/sqm |
| 5 | Pixel configuration | RGB ( SMD 3 in 1 ) |
| 6 | Red wavelength | 625± 2nm |
| 7 | Green wavelength | 525± 2nm |
| 8 | Blue wavelength | 470± 2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | more than 5 m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Vertical viewing angle | 140° |
| 13 | Maximum power consumption | ≤ 1200W/m2 |
| 14 | Brightness | ≥ 3000cd/m2 |
| 15 | Gray scale | 16bits of per color |
| 16 | Color temperature | 6500K |
| 17 | Control method | Asynchronization with 3G |
| 18 | Driving method | 1/8 scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | ≥ 2000 Hz |
| 21 | Working voltage | AC220V/110V± 10% |
| 22 | IP grade | IP65 |
| 23 | Working temperature | -20° C~80° C |
| 24 | MTBF | More than 10, 000 hours |
| 25 | Life span | More than 100, 000hours |
Applications:
Competitive Advantage:
1. Automatic production. More than 90% production process is automatic.
2. Quality control. We can control the quality of the original materials by ourselves, such as we can do the encapsulation for LEDs by ourselves.
3. The most competitive price. Because most of the original material we can produce by ourselves. So the cost for us is lower too.
4. The most professional technical support. We have been in this industry almost 10 years, we have a lot of experience to resolve all kinds of problems.
5. The best customer service. We can offer you the best customer service both before and after sales. You can reach us 24 hours every day and 7 days a week.
6. Two years warranty. We are confident about our products quality, so we have no problem at all to offer customers two years warranty.
