10mm Pixel Pitch Hd Electronic Led Sign Commercial Advertising Led Digital Billboard
Price:
1-10000usd/sqm
MOQ:
1pc/1sqm
Delivery Time:
7-15 working days
Brand:
Meltonled
Product Description
hd high quality electronic led sign, led digital billboard, ledcommercial advertising display screen
Specifications
| Item | Techinical Specifications | |||||||||||||||||||
| Pixel Pitch | 8mm | 10mm | 12mm | 16mm | ||||||||||||||||
| LED Configuration | SMD 3-in-1(SMD3535) | DIP246 (1R1G1B) | DIP246 (1R1G1B) | DIP246 (1R1G1B) | ||||||||||||||||
| Pixel Density | 15625 pixels/sq.m | 10000 pixels/sq.m | 6944 pixels/sq.m | 3906pixels/sq.m | ||||||||||||||||
| Module Size | 256mm*128mm | 160mm*160mm | 192mm*192mm | 256mm*128mm | ||||||||||||||||
| Module Resilution | 32pixel*16pixel | 16pixel*16pixel | 16pixel*16pixel | 16pixel*8pixel | ||||||||||||||||
| Cabinet Size | 1024mm*1024mm | 960mm*960mm | 960mm*960mm | 1024mm*1024mm | ||||||||||||||||
| Cabinet Resolution | 128pixels*128pixels | 96pixels*96pixels | 80pixels*80pixels | 64pixels*64pixels | ||||||||||||||||
| Cabinet Material | Iron/Aluminum | Iron/Aluminum | Iron/Aluminum | Iron/Aluminum | ||||||||||||||||
| Cabinet weight | 50kg/sqm or 40kg/sqm | 50kg/sqm or 40kg/sqm | 50kg/sqm or 40kg/sqm | 50kg/sqm or 40kg/sqm | ||||||||||||||||
| Brightness | 6000cd/sqm | 8000cd/sqm | 7500cd/sqm | 8500cd/sqm | ||||||||||||||||
| Colour temperature | 3500K-9500K(adjustable) | 3500K-9500K(adjustable) | 3500K-9500K(adjustable) | 3500K-9500K(adjustable) | ||||||||||||||||
| Viewing Angle | H:140°/V:140° | H:110°/V:55° | H:110°/V:55° | H:110°/V:55° | ||||||||||||||||
| Brightness Uniformity | ≥97% | ≥97% | ≥97% | ≥97% | ||||||||||||||||
| Ave. Power consumption | 240 W/sqm | 200 W/sqm | 200 W/sqm | 240 W/sqm | ||||||||||||||||
| Max. Power consumption | 800W/sqm | 600W/sqm | 600W/sqm | 800W/sqm | ||||||||||||||||
| Best Viewing Distance | ≥8 | ≥10 | ≥12 | ≥16 | ||||||||||||||||
| Contrast ratio | 5000:1 | 5000:1 | 5000:1 | 5000:1 | ||||||||||||||||
| Frame rate | 50/60 Hz/sec | 50/60 Hz/sec | 50/60 Hz/sec | 50/60 Hz/sec | ||||||||||||||||
| Refresh rate | ≥1200Hz | ≥1200Hz | ≥1200Hz | ≥1200Hz | ||||||||||||||||
| Drive Mode | 1/4 scan | 1/4 scan | 1/4 scan | Static contant current | ||||||||||||||||
| Brightness Adjustment | Manual/Auto/Programmable | |||||||||||||||||||
| Input Voltage | AC220V/50HZ or AC110V/60HZ (±10%) | |||||||||||||||||||
| Output Voltage | 5V,40A | |||||||||||||||||||
| Grey scale levels | R(256bit) x G(256bit) x B(256bit) | |||||||||||||||||||
| Display Colors | R(1024) x G(1024) x B(1024) | |||||||||||||||||||
| Protection Level | IP65 | |||||||||||||||||||
| Life-span | 100,000 hours | |||||||||||||||||||
| MTBF | 10,000 hours | |||||||||||||||||||
| Malfunction dot rate | < 0.0001 | |||||||||||||||||||
| Storage Temp/Humidity | -40~+65℃/10~90%RH | |||||||||||||||||||
| Operating Temp/Humidity | -20~+65℃/10~90%RH | |||||||||||||||||||
| Control System | Synchronous/Asynchronous/Wifi/3G Wireless for choice | |||||||||||||||||||
| Input Signal | RF,TV,RGB,S-VIDEO,PAL,DVI,HDMI,VGA,SDI,AVI,RGBHV,CVBS,etc | |||||||||||||||||||
| PC Operating System | Microsoft Windows 7, 8, 98, 2000, XP and Vista | |||||||||||||||||||
Function and Technology Character
(1)High bright:7500cd/m2
(1)High bright:7500cd/m2
(2)Vision angle:+140°
(3)Different languages:English/chinese/Japanese/Korean/Hebrew/Spanish and so on.
(4)Can input and change information by your computer(with software and USB interface)
(5)Can save 70 messages,every message is made up of 512 english characters
(6)Dot matrix:16*16
(7)Support Hypertext messages,many messages can be combined and display as your demand.
(8)Can set the font size and font color as you need.
(9)Support BMP/JEPG/GIF format,support flash format.
(10)Can adjust the brightness by manual or can set the brightness by computer.
(11)Can set the time/date of every message
(12)Can on/off by manual or automatically.
(13)Can be with clock and battery(When the power is cut off,it will not be off),can show time between messages.
(14)Power:25W,working temperature:-10°C- 49°C,working humidness:0%-95%
(15)Adapter:AC110V/220V
Payment and Shipping
Many different payment terms are available for Babbitt.
Babbitt is willing to help you arrange the international transportation to your places and countries via different modes of transportation.
