Aluminum Cabinet HD Outdoor Waterproof Led Advertising Screen P6 P8 P10
P6 P8 P10 HD Outdoor Led Screen Waterproof Led Advertising Screen
1.Seamless-joint :Unique connection, the gap between cabinet can be adjusted, show a perfect picture,
forming mold at a time , the processing accuracy of 0.1mm, easy to realize seamless-joint.
|
Unit Module |
Item | Parameter |
| Model Number | P10-2S | |
| Module size | 320mm*160mm | |
| Pixel pitch | 10mm | |
| Pixels Density | 10000dots/m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD3535 | |
| Pixel resolution | 32dots(W)*16 dots(H) | |
| Max Power | 25W | |
| Module thickness | 17.05mm | |
| Weight | 0.37kg | |
| Drive type | Constant drive | |
| Scan mode | 1/2can | |
| Port type | HUB75 | |
| Brightness of white balance | ≥7000cd/m2 |
|
LED Cabinet |
Dimension | 640mm*640mm |
| Monomer Module Number | 8 | |
| Power supply | 5V/60A*1 pcs | |
| Thermal discharge | fan 2pcs | |
| Pixel per cabinet | 64mm*64mm | |
| Best viewing distance | 10M～50M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature |
storage:-35℃～+85℃ 工working:-20℃～+50℃ |
|
| Relative humidity | 10%-95% | |
| Thickness | 85mm |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 195W/㎡ | |
| Max.Power consumption |
≤487W/㎡
|
|
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
|
Main technical parameter |
Driving device | Constant drive IC |
| Refresh frequency | ≥3600HZ | |
| Grey scale/colors |
4096 16.7M 4096gray level/16.7M colors |
|
| MTBF | ≥9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 |
IP65 degree of protection, the use of fully waterproof modules, modular suite of anti-UV,
After service
Technical service
(1) Provide installation training, be able to achieve the system installation and maintenance;
(2) We are responsible for the training of your staff's use;
(3) 1.5% Spare parts free of charge which are complete module or power supply, through training, the user can easily replace the spare parts, so as to ensure the normal operation of the system;
(4) Warranty: 2 year
FAQ
Q1:What's the min order quantity?
A: LED screen 1 sqm / LED module 100pcs
Q2: What is the payment method?
A:We support a variety of payment methods. Normally by T/T,30% down payment,70% balance paid before shipping.
Q3: Is it ok to print my logo on led display product?
A: Yes, of course. If you need, pls inform us before our production.
Q4: How long is the delivery time?
A: It's about 15-25days after confirmation of the order.
Q5: How do you ship the goods and how long does take to arrive?
A: We usually ship by sea or air. By sea is about 30-40days; by air is about 3-7days.
Q6: What's the control system do you use?
A: Our standard control system is Linsn or Novastar. Also support other controlling system, like Huidu,Sheenled,Colorlight etc.
