1R1G1B P5 Outdoor Full Color LED Display Advertising Panel 2-3 Years Warranty
Super Sale Outdoor P5 Full Color LED Advertising Panel Display
TECHNICAL PARAMETER
| Unit Module | Item | Parameter |
| Model Number | P5-8S | |
| Module size | 320mm*160mm | |
| Pixel pitch | 5mm | |
| Pixels Density | 40000dots/m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD1921 or 2525 | |
| Pixel resolution | 64dots(W)*32dots(H) | |
| Max Power | 45W | |
| Module thickness | 17.05mm | |
| Weight | 0.45kg | |
| Drive type | Constant drive | |
| Scan mode | 1/8scan | |
| Port type | HUB75 | |
| Brightness of white balance | ≥5500cd/m2 |
LED Cabinet | Dimension | 640mm*640mm |
| Monomer Module Number | 8pcs | |
| Power supply | 5V/40A*2 pcs | |
| Thermal discharge | fan 1pcs | |
| Pixel per cabinet | 128mm*128mm | |
| Best viewing distance | 5M～100M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature | storage:-35℃～+85℃ working:-20℃～+50℃ | |
| Relative humidity | 10%-95% | |
| Thickness | 85mm |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 390W/㎡ | |
| Max.Power consumption | ≤980W/㎡
| |
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | ≥1920HZ | |
| Grey scale/colors | 65536gray level/16.7M colors | |
| MTBF | ≥9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 |
