Fixed led Advertising Billboard Video Screen Outdoor Waterproof P8 5000CD/sQM
Price:
USD517.93-USD532.74 per sqm
MOQ:
1pc
Delivery Time:
5-15days
Brand:
Melton
Product Description
Outdoor Waterproof P8 Fixed Advertising Video Screen SMD LED Display Billboard Out of Home Advertising Pantalla
| renta de pantallas led parameter | ||
| Pixel Information | Pixel Pitch | 8mm |
| Pixel Density | 15625 Pixels/m2 | |
| Pixel Configuration | 1R1G1B | |
| LEDs Brand | Red: Silan/ Epistar / Cree | |
| Green:Silan/ Epistar / Cree | ||
| Blue: Silan/ Epistar / Cree | ||
| LEDs Wavelength | Red: 615 nm - 625 nm | |
| Green: 520 nm - 535 nm | ||
| Blue: 465 nm - 475 nm | ||
| LED Module | Module Size | 256 mm (Width) × 128 mm(Height) = 0.033/m² |
| Module Resolution | 32 pixels(Width) × 16 pixels(Height) = 512 pixels | |
| LED Cabinet | Cabinet Size | 1024 mm(Width) × 768mm(Height) = 0.79/m² |
| Cabinet Resolution | 128 Pixels(Width) × 96 Pixels(Height) = 12288 Pixels | |
| Total QYT Module Per Cabinet | 4 Modules(Width) × 6 Modules(Height) = 24 Module | |
| Cabinet Weight | 38 kgs | |
| Cabinet Material | Steel or aluminum | |
| Power | Input Voltage | 110-240V AC, 50/60Hz |
| Max Power Consumption | 1000 Watt/ m² | |
| Avg. Power Consumption | 500 Watt/ m² | |
| Viewing | Brightness | ≥7000cd/m2 |
| Brightness Uniformity | Luminance Discrepancy < 4% | |
| Colors | 16777216 | |
| Grey Scale(Level) | 4096 | |
| Slot Between Neighboring Modules | < 0.5 mm | |
| Best Viewing Angle | Horizontal:120°/ Vertical:60° | |
| Viewing Distance | 15-200 Meters | |
| Ambint Conditions | Temperature Range | Storage:-40 °c to +85°c.; Working:-20°c to +60°c |
| Operating Humidity | 10%-90%RH | |
| Ingression Protection Grade | Front Side: IP65 (Resist spraying of water gun directly); | |
| Back Side: IP54 (Resist Rain) | ||
| Processing | Scanning Mode | Real Pixel , 1/4 Scan |
| Refresh Frequency | 180HZ-600HZ, Adjustable | |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 | |
| Controller | Linsn, Xixun, DB-star, Nova-star,etc. | |
| Other | Life Span | 80,000 - 100,000 Hours |
Advantages
1.High brightness:Above 8500 nits/sq.m
2.High Refresh Rate:≥1920Hz,Take clear picture with mobile phone
3.Ultra Thin Design:the thickness of cabinet with backdoor is only 12cm
4.Fast and easy to assemble:There have fast lock between cabinet side
Applications
Outdoor Advertising use, applicable to stadium, commercial purpose, bank, stock market, savings,quay, shopping mall, bus station, telecommunication, police, monitor, school,restaurant,hotel, pub, firm, ect.
