DC 5V Full Color Led Display Board High Brightness SMD 2121 3~5 Years Warranty
China manufacturer low price P3 indoor Full Color LED Screen Panel Board Display
TECHNICAL PARAMETERS(Only for reference, Exactly according to the real screen module)
|
Unit Module |
Item | Parameter |
| Model Number | P3-32S | |
| Module size | 192mm*96mm | |
| Pixel pitch | 3mm | |
| Pixels Density | 111111dots/m2 | |
| Pixel configuration | 1R1G1B | |
| Package mode | SMD 2121 | |
| Pixel resolution | 64dots(W)*32dots(H) | |
| Max Power | 25W | |
| Module thickness | 12-14mm | |
| Weight | 0.18kg | |
| Drive type | Constant drive | |
| Scan mode | 1/32scan | |
| Port type | hub75/HUB3.0 | |
| Brightness of white balance | ≥1200cd/m2 |
|
LED Cabinet |
Dimension | 576mm*576mm |
| Monomer Module Number | 18 | |
| Power supply | 5V/60A*1 pcs | |
| Thermal discharge | anto | |
| Pixel per cabinet | 192*192dots | |
| Best viewing distance | 6M～40M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature |
storage:-35℃～+85℃ working:-20℃～+50℃ |
|
| Relative humidity | 10%-95% | |
| Thickness | 80mm |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 270W/㎡ | |
| Max.Power consumption |
≤680W/PC
|
|
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
|
Main technical parameter |
Driving device | Constant drive IC |
| Refresh frequency | ≥1200HZ | |
| Grey scale/colors | 4096gray level/16.7M colors | |
| MTBF | ≥9000hours | |
| Fire rate | Grade one | |
| Display Mode | ≥800*600/1024*768 |
PRODUCT FEATURES
1. High refresh rate: With NOVA STAR control system, no scanning line when photographed
2. High gray level: 256 RGB each, display 16.7M colors, vivid and perfect video effect
3. High resolution: The most apparent features of the new generation of LED display
4. Good color uniformity: With brand Lamp Nationstar and high refresh MBI5124 IC.
5. High Brightness: 6000-8000 CD/m2, brightness automatically adjusted
6. Long life span: Over100, 000hours, warranty from 2 to 5 years.
7. You need = We design: Provide Personal- Customized LED offer.
FAQ
1. How long could i receive the inquiry reply ?
A: You will get a reply within 12 hours.
2.How to proceed an order for led display?
A: Firstly let us know your requirements or application
Secondly we quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places deposit for formal order.
Fourthly we arrange the production
3.What kind of led display do you offer ?
A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty
4.How long will it take to deliver goods ?
A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.
